Scorpio Technology is now stocking a range of Physics related products. We will be expanding our range over time. If there is anything that you may be interested in ordering that is currently not in our product range, please don’t hesitate to email us at sales@scorpiotechnology.com.au. We’ll see if we can help.

In the meantime, have a look in our Product Catalogue with a more comprehensive listing of our other items, as you may find something of interest or useful for your Physics or Science class.

Physics Pre order website home page image.jpg

ATTENTION SENIOR PHYSICS TEACHERS AND LAB TECHNICIANS

Our Physics range is expanding and we want you to share in our excitement!

INTRODUCTORY OFFER

During SEPTEMBER you can pre-order from our 2020 Physics Pre-Order and Special Product Order Catalogue. Some of these items are ONLY available for order at this time (expected delivery late January 2020). Not all of these items will be available from us in the near future.

Discount prices will apply to some products during this period.

T&C – Orders must be received by our sales office no later than 30 September 2019.

FORCES,ENERGY & MOTION


BALLISTICS CAR

Code: PH0355APL

· The apparatus consists of a heavy metallic barrel mounted vertically on an aluminium car

· The car has plastic wheels with ball bearings to minimize friction

· Spring loaded piston arrangement

· Complete with steel balls and a lock-pin with card

· With instructions

(Model supplied may vary slightly from illustration)

Price: $95.00

PH0343 Projectile Launcher.jpg

PROJECTILE LAUNCHER

Code: PH0343

Durable, unbreakable. Aluminium construction with hardened steel latches. String release trigger mechanism with 2 bore sights. Pivots from horizontal to 90 degrees. 19 mm diameter ball with hole is easy to use fixed launch position. Trajectories vary less than 1 cm because ball does not spin when launched.

Includes assembled spring loaded gun, two balls of aluminium, protractor, plumb bob and complete with operating instructions.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $92.00


LOOP THE LOOP

Code: PH0323LL

· Demonstrates transformation of potential energy into kinetic energy

· Large imposing unit sure to impress

· A steel ball, let loose at upper end of the loop, transverses the track at a fast speed without falling, while climbing the upper track of the loop

· Stands 50cm tall

· Outstanding DEMO in potential energy, kinetic energy, angular momentum and gravity!

Price: $71.50

PH0323LS Loop the Loop with Scale.jpg

LOOP THE LOOP WITH SCALE

Code: PH0323LS

To demonstrate transformation of potential into kinetic energy. For demonstration of conservation of energy, momentum and projectile motion. Loop the Loop looks like the track of a roller coaster. The curved metal track allows you to drop a steel ball from the top and watch the results.

Depending on the height at which it is dropped the ball will roll completely around the interior of the track or will drop to the ground. A circular scale is attached to the device for measuring the angle at which the ball drops and the track is also graduated to determine the distance. Includes steel ball.

Base Size 38 x 15cm Height 53 cm. Supplied with manual.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $84.00; ($77.50 special pre-order price)

PH0351 Dynamic Trolley Pair.jpg

DYNAMIC TROLLEY - METAL (PAIR)

Code: PH0351

· Compact design

· One end of the metal body carries an integral plunger / trigger system for explosion experiments

· Other end of metal body has a clamping screw for attaching ticker tape

· Includes built-in Velcro pads for non-elastic collisions & locating pins allowing secure stacking of two or more dynamic trolleys

Price: $79.00

Fan Car Catalogue cropped.jpg

FAN CAR

Code: FANCAR

· Designed to examine Newton’s Laws of motion, inertia, acceleration and action/reaction

· Demonstrate what happens when sail is added or removed when fan is switched on

· Features adjustable/removable sail

· Dimensions: 180mm x 150mm x 200mm

· 4 x AA batteries required (not included).

Price: $33.80

3568-00  Newtons Fixed Angle Fan Cart.jpg

NEWTON’S FIXED ANGLE FAN CART

Code: 3568-00

· Ideal for displaying Newton’s laws of motion, force, acceleration, and mass in action

· Easy to use, making it perfect for demonstration of these principles in any classroom

· Comes with removable sail, to display action-reaction and to control motion, as well as battery clips

· Shows the impact of different net forces on acceleration

· Requires one or two AA batteries (not included)

· With teacher’s guide

Price: $56.00


ROMAN ARCH

Code: EMAR

· Force & geometry combine to build an ingenious structure

· Excellent for use in the study of physics (static equilibrium), architecture and practical maths applications.

Price: $52.00


NEWTON’S SPRING BALANCES

Code: PH0033A

Newton Spring Balances - Tubular - Capacity: 100gm, Newton 1N, Sub-division 2gm

Code: PH0033B

Newton Spring Balances - Tubular - Capacity: 250gm, Newton 2.5N, Sub-division 5gm.

Code: PH0033C

Newton Spring Balances - Tubular - Capacity: 500gm, Newton 5N, Sub-division 10gm.

Code: PH0033D

Newton Spring Balances - Tubular - Capacity: 1kg, Newton 10N, Sub-division 20gm.

Code: PH0033E

Newton Spring Balances - Tubular - Capacity: 2kg, Newton 20N, Sub-division 40gm.

Code: PH0033F

Newton Spring Balances - Tubular - Capacity: 3kg, Newton 30N, Sub-division 60gm.

Code: PH0033G

Newton Spring Balances - Tubular - Capacity: 5kg, Newton 50N Sub-division 100gm

Price: $9.95 (each)

PH0318 Falling Bodies Apparatus Projectile Apparatus.jpg

FALLING BODIES APPARATUS

Code: PH0318

Demonstrate the effect of gravity on falling bodies

L-section launcher with holes for locating two 19 mm diameter steel balls which act as projectiles. Launcher is released by push button and projects one ball forward while allowing the other to fall freely. Launching mechanism mounted on wooden block 180 x 60 x 30 mm which may be clamped by bench and has a convenient storage pocket for the balls, complete with two steel balls.

Price: $32.20

PH0343A Hall's Carriage.jpg

HALL’S CARRIAGE

Code: PH0343A

For Dynamics experiments.

The one-piece aluminum wheels and axles mounted in cone bearings for low friction operation. One piece plastic body with facility to add weights on the top. Size 13.5 x 7 x 3.5 cm

Used with inclined planes.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $24.10 ea; ($20.90 ea {10+ units} special pre-order price).

AR1030838 Study of Ballistics Kit.jpg

STUDY OF BALLISTICS, KIT

Code: AR1030838

Ballistics is the science of mechanics that deals with the launching, flight, behavior and effects of projectiles.

Whole assembly is fitted on a metallic base. A knob is provided to adjust the launching angle from 0°-90°. Hardened spring and metallic trigger is provided to launch the rocket.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $97.75 ($93.75 special pre-order price)

AR1030978 Acceleration Motion Kit with Photo Gates.jpg

ACCELERATION MOTION KIT WITH PHOTO GATES

Code: AR1030978

Acceleration Motion Kit is useful to study the motion in plane and slopes. This kit consisting 1 meter long horizontal aluminum track, graduated 0-900 mm. Three supports are provided along the length of the track and are adjustable. Two photo-gates are also located on the horizontal track. A level adjuster knob is provided on one end of the track. Track also has a provision to change its slope.

Supplied complete with one solenoid of 5V and polished Iron ball of 19mm.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $386.00

PH0355IA Inertia Apparatus.jpg

INERTIA APPARATUS

Code: PH0355IA

Demonstrate inertia in a simple experiment

Perfect for middle, high school or even basic university physics

Stand with a receptacle for the 18mm metal ball at the top. Ball, a square piece of sheet metal and a trigger of sheet metal included. Pulling and releasing the trigger causes the square sheet to slide out from under the ball, dropping the ball in the receptacle by inertia.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price:$21.10

PH0362SET Precision Air Track.jpg

PRECISION AIR TRACK SYSTEM

Code: PH0362SET

Absolutely everything needed to set up and run this air track as a nearly friction-less environment. System will cover all fundamentals of dynamics and newtons laws, motion, force, momentum, conservation of energy, etc. No need to spend hours piecing together systems, everything is included.

System can be used with any photogates (Neulog, Vernier, Pasco, Fourier, etc).

Included: 2m Air track (1); Blower and Plug for air track (1); 120gm Slider with mounting bracket (2); Attachment Nuts (1); Spring Attachments (4); Connection Bracket (for springs, string, etc.) (4); 2 inch spring (2); 4 inch spring (2); Male Verlco Bumper (2); Female Velcro Bumper (2); Friction-less Pulley and Bracket (2); String (20 feet); 5gm slotted masses (9); Slotted Mass hanger (1); Photogate Interruption Screens (8); Elastic Launching Cradle / Bumper (1); 12.5 gm Slider masses (4); 25 gm Slider masses (4); Photogate/accessory attachment arm (2); Leveling Feet (3); Air Input Valve (1); Measuring Meter on track (1)

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $1250.00 (Available by pre-order only)

PLANEINC Inclined Plane.jpg

INCLINED PLANE

Code: PLANEINC

Ideal tool from demonstrating friction, acceleration, work, potential energy & vector components of force.

Smooth wooden plane 600 x 80mm, hinged to the base at one end.

Provided with a pulley for force and with scale pan and weight. Supplied with 3 friction boards, plastic cart and angled meter.

Dimensions: 645 x 125 x 400 mm (weight 2kg).

Some assembly required (requires Philips Head screwdriver - not supplied). Assembly instructions included.

Price: $69.50


HYDRAPULT

Code: WM6720

· Uses hydraulics to throw projectiles in 3 different ways; Suitable for programs related to robotics, levers & simple machines, fluid dynamics, density, air resistance & engineering.

· Soft clay included

· For ages 8+

Price: $25.00

PH0349ECB Newton's Cradle Economy Balls.jpg

NEWTON’S CRADLE

Code: PH0349ECB

· Demonstrates Newton’s Third Law

· Some assembly required

(Item supplied may vary from illustration)

Price: $33.00

5146-00 Newton's Apples 6 pack.jpg

NEWTON’S APPLES - 6 PACK

Code: 5146-00

Learn about Newton’s 2nd law, gravitational force & energy with these clever little apples.

Feel the force of 1 Newton and learn about how scientists measure force. These soft mass red apples, weighing at 102 grams each, are a useful prop for classrooms. They are great for illustrating the principles of physics.
• Comes with a Teacher’s Guide
• Comes with Instructions.

Price: $49.95

PH0355DYTR Dynamics Track, Stand & Ramp.jpg

DYNAMIC TRACK, STAND & RAMP

Code: PH0355DYTR

Made of Hardwood. Ramp size: 30cm (W) x 120cm (L). Complete with height adjustable support (max height is 65cm) and run off ramp to bridge the gap between track and floor when required.

The track bases are in thick MDF with hardwood side supports which give good resistance to flexing. Rounded corners avoid injuries.Support feet link with the support frame which provides a robust system for height adjustment. Complete with run off ramp to bridge the gap between track and floor when required.

Price: $129.50

(LOW STOCK LEVELS - PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.)

PH0352 Trolley Runway.jpg

TROLLEY RUNWAY

Code: PH0352

Made of wood, Size 1.5 x 0.3 meters.

Designed to provide a smooth flat easily inclinable surface for dynamic experiments using trolleys. With wooden sides rails and plastic feets.

Supplied without dynamic trolleys (sold separately).

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $115.00 ($107.00 special pre-order price)

PH1120147 Rolling Friction Cars bottom view.jpg

ROLLING FRICTION CARS

Code: PH1120147

he rolling friction car kit provides four cars for exploration into the force of friction. Each car provides a set of different material wheels (wood, fabric, soft rubber, soft silicone) with a different coefficient of friction. By setting the cars in motion with equivalent velocities, one can qualitatively demonstrate the frictional properties of rolling without slipping.

Instruction manual included.

NOTE: Photo is of the base of the cars to show the different material wheels.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $59.95 ($54.95 special pre-order price)

AR1030898 Arco Projectile Launcher with Photo Gate.jpg

PROJECTILE LAUNCHER WITH PHOTO GATE

Code: AR1030898

Comprises an aluminum track supported by a metal rod on a stable base with level adjuster knobs. A vertical scale, to adjust the height of the release of projecting ball through a solenoid, is printed on the board. The instrument allows metallic balls to be launched at different horizontal speeds depending upon the height of release of balls. This allows investigation into a number of different aspects of energy and momentum studies.

Accessories:

• Solenoid, 5V operated; • Polished MS Ball ½”; • Photo-gate

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $135.00

PH0311 Inertia Ball.jpg

INERTIA BALL

Code: PH0311

Great for numerous inertia labs. Heavy duty 455 g metal ball.

This is a demonstration of Newton’s First Law of motion. Suspend the metal ball from the ceiling and attach a second string. What happens when you pull steadily on the lower string? What if you jerk it quickly? The ball can also be used as Pendulum bob. Fitted with 3 eye bolts.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price:$22.50 ea ($18.50 ea special pre-order price)

GFYE14-V2 G by Free Fall App Economy Timer 220V.jpg

“G” BY FREE FALL APPARATUS - ECONOMY UNIT WITH TIMER - 220V

Code: GFYE14-V2

The determination of the gravitational constant ‘g’ is one of the most fundamental and early physical constants students must derive and observe.

This economical kit has a wooden base, 1.1m rod and a movable electro magnet. The electromagnet can be moved anywhere on the rod and is powered by the timer. When the ball is released the timer is triggered and stopped one the ball his landed on the base for a precise measurement and then calculation of ‘g’.

Supplied with manual.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $249.00

PH0362GTACC Compatable Photogate Timer Acc set in Gratnell storage Tray.jpg

COMPATIBLE PHOTOGATE TIMER ACCESSORIES SET IN GRATNELL STORAGE TRAY

Code: PH0362GTACC

Compatible photogate timer system for PH0362SET (Precision Air Track System). The complete photogate system with photogate & interrupter plates.

With activity guide. Supplied in Gratnell tray.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $560.00 (Available by pre-order only)



HEAT & THERMODYNAMICS - METALS


RODS FOR THERMAL CONDUCTIVITY EXPERIMENTS – SET OF 8

Code: TCRODS3X130

· Set of 8 rods for thermal conductivity experiments: Iron, Copper, Brass, Lead, Aluminium, Stainless Steel, Tin & Plastic

· Rods sizes: 100-130mm long x 3.0mm diameter

Price: $18.00


RODS FOR THERMAL CONDUCTIVITY EXPERIMENTS - SET OF 6

Code: PH0397

Which metal is the better conductor?

Set of 6 300mm long x 3mm diameter rods: Iron, Copper, Aluminium, Lead, Brass & Zinc

Price: $26.90

Thermal Conductivity Bar.jpg

THERMAL CONDUCTIVITY BAR

Code: TCBAR

· Ideal apparatus for the comparison of the thermal conductivity of different metals quickly and conveniently

· Features convenient liquid crystal indicators mounted in robust holders that show how a red zone of 40⁰C moves up the bars

· Comprises of four metal bars of the same shape & size

· The tip of the heated bars are immersed into cold water to show how conductivity applies to heat leaving the metal

· The tops of the bars are designed to be touched with a fingertip to reinforce the colour observations of the bars

Price: $29.00

Ball and Ring.jpg

BALL & RING - GRAVESANDE’S - CHAINLESS

Code: TCBALLRNC

Used to demonstrate thermal expansion.

When the ball is at room temperature, it will pass through the ring, but when the ball is gently heated, it will no longer pass through.

Ball size including handle length: 250 x 20mm

Ring size including handle length: 260 x 38mm.

Price: $18.00


CONDUCTIVITY RING

Code: HL0910-001

· The IEC conductivity ring is the classic device to demonstrate the different heat conductivity of different metals

· 4 strips of iron, copper, brass and aluminium fixed to an aluminium ring

· Pea-sized amount of wax is placed into the depressions at the end of each ring and the centre of the device placed on a Bunsen burner to heat the 4 metal rings evenly

· Compare the heat conductivity of each metal by observing the melting of each particle of wax.

Price: $32.00

Thermal Conductivity of Metals.jpg

THERMAL CONDUCTIVITY OF METALS APPARATUS

Code: TCCONDMTR

· Conductometer type

· Demonstrates the diverse thermal conductivity of 5 distinct metals: aluminium, brass, iron, stainless steel & copper

· Place a small amount of supplied wax over each metal spoke

· Heat the central hub over a Bunsen burner flame & watch the differing rates at which the wax melts

· Wood handle mounted

· 2 concave test points in each metal rod

· Size: approx. 395 x 185 x 20mm

Price: $21.00


SPECIFIC HEAT CYLINDERS – EQUAL SIZE

Code: PH0434

· Set of 6 specific equal in size heat cylinders

· 38mm x 9.5mm

· Copper, lead, brass, zinc, iron and aluminium

· With stand

Price: $37.50

CBP0403 Practical Bimetallic Thermostat.jpg

PRACTICAL BIMETALLIC THERMOSTAT MODEL

Code: CBP0403

· This device automatically responds to temperature changes which activates a switch

· Consists of a vertically bimetallic strip with binding posts and adjustable contacts

· Practical uses include controlling heating systems, air-conditioners, fridges, etc.

· Get this one for reinforcing the message!

Price: $44.65

PH0426 Thermocouple - 4mm terminals.jpg

THERMOCOUPLE - 4MM TERMINALS

Code: PH0426

· Copper / constantan 305mm with 4mm terminals; Produce an electric current simply by heating.

· Connect to a galvanometer.

· More sophisticated units are used for measuring temperature. This one is a good starter to explain the concept.

Price: $16.50

PA0428 Bimetallic Thermopile.jpg

BIMETALLIC THERMOPILE

Code: PH0428

· Four copper & four iron wires, approx. 130mm lengths, twisted together to form junctions, four on one side, three on the other

· Includes brass connectors

· In other words, we have a series of thermocouples in use for generating thermoelectric current

· Use with a galvanometer

· Produces more current than a single thermocouple and is also a good starter to explain temperature measurement

Price: $13.50

TCRING Heat Conductivity Ring - Wood Base.jpg

HEAT CONDUCTIVITY RING - WOOD BASE

Code: TCRING

· Demonstrate the heat conductivity of metals

· Metal strips - one each of: copper, brass, iron and aluminium; Fixed to a 13cm diameter wooden ring

· Depressions at the end of each strip to place wax piece; Compare the heat conductivity of each metal by observing the melting of each piece of wax

NOTE: Do not use on a Bunsen burner as it will damage the metal strips. Use an alcohol burner due to its lower heat level.

Price: $17.50



ELECTROSTATICS


ELECTROSTATICS KIT

Code: PH0900

· Complete electrostatics kit with manual supplied

· Comprises of 1 x electroscope, 4 metallised polystyrene spheres, 1 x reel nylon, 1 x cellulose acetate strip, 1 x polythene strip, wire stirrup, wool cloth, wire hook, electrophorus on handle & proof plane

· 2 x polythene tiles & 2 x aluminium cans

Price: $76.00

PH0916B Gold Leaf Electroscope.jpg

GOLD LEAF ELECTROSCOPE

Code: PH0916B

This gold leaf electroscope is great for hands on experience with electrostatic principles in physics classrooms and labs. The solidly constructed sheet anodized aluminum walls of the electroscope are mounted on a plastic base. Front glass window slides up to allow insertion of ionizing material in chamber. Transparent scale is attached inside chamber to measure the deflection of the gold leaf.

Comes with two gold leaf sheets. Fitted with 4mm socket. Assembled, the electroscope measures 6.5 x 3.75 x 2.75 inches.

NOTE:: The gold-leaf does not come pre-attached to the electroscope. Instructions on how to properly attach the gold-leaf to the conducting rod are included with the product manual.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $52.95

EM1770-001 Simple Electrostatics Kit, PSSC.jpg

SIMPLE ELECTROSTATICS KIT, PSSC

Code: EM1770-001

· A simple kit with a variety of mate suitable for basic electrostatic experiments

· Use plastic strips and rubbing cloths to produce positive and negative charges

· This kit contains the following items:

• 9 pieces Polystyrene Balls

• 2 pieces Cloth, Cotton

• 2 pieces Cloth, Woollen

• 6 pieces Wooden Clothes Pegs

• 1 piece Nylon Filament x 3.5 metres long

• 1 piece Small Paint Brush

• 1 piece Bottle graphite in Alcohol - 25ml

• 6 pieces Insulators, polythene, 130 x10 x 3mm

• 5 pieces Pins

• 5 pieces Acrylic Strip, transparent, 3mm thick, (replaces older style acetate strip but produces same polarity charge)

• 5 pieces Vinyl Strip, approx.1mm thick.

Visit www. http://iecpl.com.au/z_pdfs/em1770-001.pdf for more details.

Price: $44.00

EM1775-001 Electrostatic Pith Balls Conductive.jpg

ELECTROSTATIC PITH BALLS – CONDUCTIVE COATING

Code: EM1775-001

· Set of 10 pith balls with conductive coating for use in electrostatics experiments

· The balls are not fully round by are generally shaped as a ball

· The conductive pith balls carry the electrostatic charge all over their surface and the whole surface charges or discharges

· Diameter: 10mm (approx.)

Price: $6.70 (Set of 10)

EM1774-001 Electrostatic Pith Balls Plain.jpg

ELECTROSTATIC PITH BALLS - PLAIN

Code: EM1774-001

· Set of 12 plain pith balls with 8mm diameter (approx.) for use in electrostatics experiments

· The balls are not fully round by are generally shaped as a ball

Price: $5.05 (Set of 12)

EM1772-001 Electrostatic Rubbing Cloths.jpg

ELECTROSTATIC RUBBING CLOTHS

Code: EM1772-001

· Set of 2 cloths: cotton flannelette & wool; Size of each cloth: 200mm x 200mm (approx.)

· Used for rubbing on electrostatic rods for the creation of electrostatic charges

· The edges of each piece of cloth have been overlocked to prevent fraying

Price: $7.15 (Set of 2)

Electrostatic Friction Rods.jpg

ELECTROSTATIC FRICTION RODS

Codes: PH0856A (Ebonite); PH0856 (Acrylic); PH0856B (Glass); PH0852 (Nylon); PH0851 (Polythene)

· Electrostatic rods are made up of various insulation materials

· Use the rods to rub against different fabrics such as faux fur, cotton, etc., to create static electricity

· Polythene is a type of plastic also known as Polyethylene

· Ebonite is a vulcanized rubber

· The type of rod and the type of cloth used will determine the amount of charge produced

· Rod sizes (approx.): 300mm long x 10-13mm diameter

NOTE: Length & diameter may vary with different rods and different manufacturers.

Price: $5.50 (PH0856A); $3.50 (PH0856); $3.50 (PH0856B); $8.25 (PH0852); $5.50 (PH0851)

AR1080620 Arco Wimshurst Electrostatic Generator.jpg

WIMSHURST ELECTROSTATIC GENERATOR

Code: AR1080620

A traditional device capable of generating high electrostatic potential that can produce spark of length up to 7.5cm under favourable weather condition.

Equipped with two clear acrylic plates, each of diameter about 25cm and having aluminium sectors permanently pasted radially along the rim. Both the plates mounted parallel to each other and rotate in opposite direction through a belt-pulley arrangement. Pulley on one wheel has handle for manual rotation. A set of charge collecting combs in mounted toward either end of a horizontal insulating beam, together with the adjustable spark gap arms, the latter equipped with small metallic sphere discharger at one end and long insulating handle adjustment at the other end.

The charge can be stored in a pair of high capacity Leyden jar capacitors that can be connected or disconnected as desired. When connected to the Leyden jars through a pair of levers, the spherical dischargers starts accumulating the charge and transfer of charge from one discharger to other takes place in the form electric spark jumping from one sphere to other as a consequence of build-up of sufficiently high potential difference across the two spheres. The spark produced intermittently by the continuously rotating plates. Complete apparatus is mounted on a well insulated base that also carries a pair of earth terminals for the Leyden jars.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $214.00; ($204.00 special pre-order price)

PH 0871C.JPG

ELECTROSTATIC POMPOM SET - PAIR

Code: PH0871C

When the plate is touched with an electrostatically charged rod, the cords become charged and spread out into a wide cone by mutual repulsion.

Includes pair of pompoms 18 x 10cm long.

Price: $32.50


LEYDEN JAR

Code: LEYJAR

· Shock your students again and again with this Leyden Jar.

· It comes with a durable inner and outer plate, a plastic dielectric, and directions.

· The inner plate has a hook and ball attached which makes It easy to charge.

· Use this equipment to duplicate many classic static electricity experiments.

Price: $20.00

AR1080380-2 Electroscope Pith Rail.jpg

ELECTROSCOPE, PITH RAIL

Code: AR1080380-2

Electroscope, Pith Ball, on plastic base.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $12.80 ea: ($11.80 ea (10+ units) special pre-order price).

AR1080400 Pith Balls Spare Assorted.jpg

PITH BALLS - ASSORTED SIZES

Code: AR1080400

Available as spare for Pith Ball Electroscope, AR1080380, in assorted sizes. Pack of 10.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $2.10 each pack; ($1.80 each pack {10+ packs} special pre-order price).



ELECTROMAGNETISM & ELECTRICITY

EM0603-01 Magnetism Plate 2D.jpg

MAGNETISM PLATE - 2D

Code: EM0603-01

· Iron filings suspended in oil; Ideal for magnetic pattern analysis

· Dimensions: 190mm x 100mm (approx.)

Price: $24.50

EM0602-05 Magnetic Field Observation Tank.jpg

MAGNETIC FIELD OBSERVATION TANK

Code: EM0602-05

· Used to observe magnetic force fields; Can be demonstrated with or without overhead transparency

· The tank is supplied with a magnet

Price: $143.00

EM0602-02 Magnetic Field Demo Kit w Shaker.jpg

MAGNETIC FIELD DEMONSTRATION KIT

Code: EM0602-02

· Kit contains:

2 x magnetic field panels - 200mm x 100mm that can be locked together to form one larger panel.

2 x Straight bar magnets 75 x 12 x 8mm (length x width x thickness)

1 x “U” shaped magnet 50 x 25 x 12mm (length x width x thickness)

· This kit uses clear moulded plate containing many metal pins that clearly show the path of magnetic fields when a magnet is placed upon it

· Panels can be locked together so the working area can be further expanded with more panels (EM0602-01); Can be placed on an overhead projector for student viewing

Price: $42.35

AR1070251 Arco Kit for Magnetism Experiments.jpg

KIT FOR MAGNETISM EXPERIMENTS

Code: AR1070251

Kit providing the components in a box to perform basic experiments in magnetism. The kit comprises of the following items:

1 x Test Tube; 1 x Bar Magnet; 3 x Iron Screws; 1 x Cylindrical Magnet; 1 x Knitting needle; 1 x Spool of Thread; 1 x Plastic box small; 1 x Wooden Disc; 1 x Rubber eraser; 1 x Sheet of Copper; 1 x Sheet of iron; 1 x Sheet of cardboard; 1 x Piece of cloth; 10 x Nails; 1 x Compass needle; 1 x Compass card; 1 x Hiking Compass; 1 x Paper Clips; 1 x Mini Waggons for Magnets; 1 x Filter Bowl; 1 x Aluminium Screws; 1 x Floating platform for bar magnet; 1 x Floating platform for Compass needle ; 1 x Bar Magnet with red marked north pole.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $136.00 ($130.00 special pre-order price)

PA2097-001 Magnets 75mm Pair.jpg

MAGNETS – 75MM – PAIR

Code: PA2097-001

· Pair of bar type magnets; High strength “Alnico”; Size: 75mm (l) x 12mm x 8mm

· One end painted red (points to the north and is marked “N”), the other end painted blue

· Magnets are supplied in a vial with a screw top

Price:$19.80

PA-57 U-shaped magnet Website edited.jpg

HORSESHOE MAGNET - 80MM

Code: PA-57

U-Magnetic, overall length 80mm, cross section of poles 20 x 10mm. space between poles 42mm, (350 Gauss), made of Al/Fe/C. North Pole painted red. South Pole blue. In plastic case.

NOTE: Magnets should be handled with care. Dropping magnets may result in the paint chipping.

Price: $15.85


MAGNETIC THEORY BOARD

Code: EM1070415

· Magnetic Field Demonstrator used to demonstrate the magnetic lines of forces

· 46 magnetic compasses fixed around the square plastic base

· Approx. 302 x 302mm; Easy to handle and store

Price: $60.00

PH0802 Giant Magnetic Field Demonstration Plate.jpg

GIANT MAGNETIC FIELD DEMONSTRATOR PANEL

Code: PH0802

Board of 98 chambers each containing a small iron rod. Conveniently displays configuration of a magnetic field. Can be used on overhead projector.

Price: $45.00

AR1090120 Electric Field Apparatus.jpg

ELECTRIC FIELD APPARATUS

Code: AR1090120

For investigation of electric field patterns due to various electrode configurations and also permits easy demonstration of the related concepts to a group of students through overhead projector.

The apparatus comprises a clear plastic dish and a transparent rectangular base carrying a pair of 4mm socket terminals that can also hold adjustable electrodes.

Includes a set of 6 electrodes - two point source electrodes, two line source electrodes and two circular rings of 35 and 70mm diameter respectively.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $31.05 ea. Special pre-order price: $29.00 ea {1 - 14}; $28.00 {15+}.

AR1070830 Faraday's Electromagnetic Induction Demonstrator.jpg

FARADAY’S ELECTROMAGNETIC INDUCTION DEMONSTRATOR

Code: AR1070830

For demonstrating the important experiments performed by Faraday and how they lead to some of the significant conclusions in electromagnetism. Designed to perform studies even beyond the basic experiments,

It comprises three solenoids of 20, 40 and 80 turns each of identical cross section, mounted on a transparent base along with a milliammeter. Repeatedly inserting a magnet into the coil and removing it causes electric current to flow through the coil, which can be read directly from the milliammeter. Using this apparatus, students can study correlations between induced current to that of magnetic field strength, number of turns of coil, magnetic field polarity and speed.

Requires 1.5V dry cell battery (not included), available separately.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $85.95 ($81.95 special pre-order price)

PH0800C Variable Magnet Set.jpg

VARIABLE MAGNET SET

Code: PH0800C

Variable coil electromagnet has 6 different coil options:100, 200, 300, 400, 500 and 600 coils. A hook underneath used to measure the strength of the magnetic field

To study the effect of current and number of coils on the strength of an electromagnet. Tapping at 100, 200, 300, 400, 500, 600 turns. The weights used are large paper clips. A variable D.C. low voltage supply is required.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $46.00; ($43.00 special pre-order price)

EM0602-01 Magnetic Field Panels.jpg

MAGNETIC FIELD PANELS

Code: EM0602-01

· Additional panels available for purchase to add to Magnetic Field Demonstration Kit (EM0602-02)

· Panel size: 200mm x 100mm

· No glycerine to leak

· Very sturdy – can be dropped without serious damage; Black pins that don’t jam or rust

Price: $15.90

PH0800 Junior Science Magnet Kit.jpg

JUNIOR MAGNET KIT

Code: PH0800

A kit of magnets and accessories for science experiments in a compartmental storage tray.

Contents: 1 Horseshoe magnet with keeper, 100mm 2 Ceramic bar magnets 75 mm Long. 3 Ceramic ring magnets, 38 mm dia, face polarised. 2 x Plotting compasses, clear both sides, 19 mm dia. 1 Pack Iron Filing. 1 piece. each of square iron, aluminium, zinc and copper metal.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $39.00

AR1070380-1 Arco Magnetic Field Chamber, Economical Model.jpg

MAGNETIC FIELD CHAMBER, ECONOMICAL

Code: AR1070380-1

Demonstrates three-dimensional nature of magnetic field associated with cylindrical magnets. Comprises a hollow chamber of clear acrylic with a tunnel at its center to hold cylindrical magnets.

The chamber has high quality iron filings, which aligns itself as per the magnetic field geometry of the magnet.

Also allows magnets of other shapes to be investigated by simple positioning their poles adjacent to any side of the chamber.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $32.05; Special pre-order price: $29.05

PA-56D Magnet, Alnico Pair 100x20x6mm.jpg

MAGNETS - 100MM - PAIR

Code: PA-56D

Pair of Alnico. Size : 100 x 20 x 6 mm (700 Gauss). In plastic case.

NOTE: Magnets should be handled with care. Dropping magnets may result in the paint chipping.

Price: $8.85

em0475-01 Magnet Magnetoid Pair.png

MAGNET MAGNATOIDS - PAIR

Code: EM0475-01

Pull them apart, toss them in the air and listen to them sing.
Driven by powerful magnetic attraction and repulsion, these magnets strive to stay in perfect balance with each other.

Warning: To avoid chipping, avoid dropping them onto hard surfaces

Price: $10.90

EM0555-01 Magnetic Wand.jpg

MAGNETIC WAND

Code: EM0555-01

· Permanent wand moulded in plastic

· Price per magnetic wand only (not as per illustration)

· Colour supplied may vary

Price: $5.00 (each)

PH0798MP Magnetic Field Probe.jpg

MAGNETIC FILED PROBE

Code: PH0798MP

For detecting and mapping magnetic fields

Put it anywhere where there is a magnetic field including hard to get at spots. 19mm alnico magnet is mounted in a freely rotating gimbal for 3D location and mapping. Quality plastic superstructure. Rotating Magnet Head.

Quick, easy and effective detector and inexpensive

Price: $19.80

PH0845EDU Eddy Current Unit.jpg

EDDY CURRENT UNIT

Code: PH0845EDU

· Two masses drop down a 33cm copper tube. One is steel, one is a neodymium magnet. When students see the magnetic mass fall more slowly than the steel mass, you can introduce them to electrical eddy currents.

· These currents oppose downward motion through a moving magnetic field created by the falling neodymium magnet.

· Demonstrate Lenz’s Law.

Price: $31.90

AR1090142 Field Lines & Equipotential Lines.jpg

FIELD LINES & EQUIPOTENTIAL LINES

Code: AR1090142

The kit consist of the following:

1 x Trough; 1 x Needle; 1 x Rod with socket; 1 x Multi-meter; 1 x Cylindrical base; 2 x Bar electrode; 2 x Disc electrode; 1 x Ring electrode; 1 x Stand rod; 1 x Boss head;

1 x Power supply (2-12 V AC). Output voltage 2,3,4,5,6,8,10 and 12 V AC full wave, rectified, un-smoothed and unregulated D.D in maximum 8 steps. Overload protection re settable thermal trip. Working voltage 230 V AC, 50 Hz

2 x Flexible plug lead (set)

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $578.00

AR1070710 Arco Faraday Law.jpg

FARADAY’S LAW

Code: AR1070710

For quick visualization of Faraday's Law, includes a 150-0-300 turns coil with 4mm sockets with a provision to freely slide on a transparent acrylic tube. On drooping down a cylindrical magnet through the tube a pulse of electricity is generated across the coil and can be visualized on an oscilloscope.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $70.30

EM2067-001 Magnetic Field Demonstrator Set with Shaker.jpg


MAGNETIC FIELD DEMONSTRATOR – SET OF 3 WITH SHAKER

Code: EM2067-001

· Set of 3 Magnetic Field Demonstrators with small carry case:

STRAIGHT CONDUCTOR (EM2067-010); ROUND COIL (EM2067-020); SOLENOID (EM2067-030)

· Shaker with iron filings (however, a small plotting compass can also be used to view the magnetic fields)

· Genuine IEC products

Price: $150.70

(See Instruction Sheet on IEC website for more details - http://iecpl.com.au/z_pdfs/em2067-001.pdf)

EM2067-010 Magnetic Field Demonstrator - Straight.jpg

MAGNETIC FIELD DEMONSTRATOR - STRAIGHT

Code: EM2067-010

· Consists of a rectangular coil passing through a transparent base plate to provide two vertical conductors to carry current so the field shape around a straight conductor can be demonstrated

· Can be used on an overhead projector

· Use a plotting compass or sprinkle iron filings on the base plate so that the magnetic field formed around the straight conductor can be easily observed and studied

· Size (approx.): 140 x 96 x 83mm

Price: $43.95

EM2067-020 Magnetic Field Demonstrator - Round Coil.jpg

MAGNETIC FIELD DEMONSTRATOR - ROUND COIL

Code: EM2067-020

· Consists of a round coil passing through a transparent base plate to carry current so the field shape around a round coil can be demonstrated; Can be used on an overhead projector

· Use a plotting compass or sprinkle iron filings on the base plate so that the magnetic field formed by a round coil can be easily observed and studied

· Size (approx.): 140 x 96 x 57mm

Price: $43.95

PH0799B Iron filings.jpg

IRON FILINGS - FINE

Code: PH0799B

500g jar of iron filings for magnetic field mapping.

(Warning: Not for use by young children. It is advisable to wear gloves when handling this product).

Price: $16.00

EM2067-030 Magnetic Field Demonstrator - Solenoid.jpg

MAGNETIC FIELD DEMONSTRATOR - SOLENOID

Code: EM2067-030

· Consists of a round spiral coil passing through a transparent base plate to carry current

· Magnetic field shape around a solenoid coil can be demonstrated; Suitable for use on an overhead projector

· Use a plotting compass or sprinkle iron filings on the base plate so that the magnetic field formed around the solenoid coil can be easily observed and studied.

· Size (approx.): 140 x 96 x 54mm

Price: $53.00

MAGBAR-V2 Magnetizer Box - Electrical 220 240V AC.jpg

MAGNETIZER BOX - ELECTRICAL 220 / 240V AC

Code: MAGBAR-V2

220/240V AC, 50/60HzRevitalizes iron, nickel, cobalt, and alnico horseshoe and bar magnets in seconds. Simply place magnets in the 25 x 25 mm holes and press the button to make old magnets new again.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $253.00


ELECTROMAGNET ON BASE

Code: 1070715

· An electromagnet fitted on a plastic moulded base (140 x 80 x 40mm approx.) with a maximum operating voltage 12V DC.

· Open for easy study!

Price: $27.50

PH0845HEL Helmholtz Coils.jpg

HELMHOLTZ COILS

Code: PH0845HEL

A pair of precision coils and 400 turns of wire are wound on former of about 150 mm diameter. The coil is comprised of a support rod, which fits on the holders of the track system supplied, which enables them to be aligned on a common axis for measurements and study of the magnetic fields.

Normally used in pairs, each coil has 4 mm terminals and their distance apart is adjusted over the track supplied. The maximum current in the coil is 1A to avoid overheating. Direction of current is marked on each coil.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $177.00; ($165.00 special pre-order price)

PH1229HG Hand Generator.jpg

HAND GENERATOR

Code: PH1229HG

Hand operated, housed in clear tough plastic case. Mounted lamp on the end can be used as a flash light. Can be utilized with almost any experiment requiring upto 12V DC current. Use binding post to connect outside electrical circuit.

Banana plug terminals.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $27.30; ($25.00 special pre-order price)


MAGNETISING CHARGER

Code: PH0800E

· Power up your old magnets!

· Charger for Bar and Horseshoe magnets; No electricity required

Price: $104.95

PH0800A Electromagnet U-Form Economical.jpg

ELECTROMAGNET U-FORM - ECONOMICAL

Code: PH0800A

Comprising iron U-shaped core of circular section, with armature and carrying hook.

Comprising iron U-shaped core of circular section, with armature and carrying hook. Wound with 0.46mm insulated copper wire (250 turns). Provided with two, 4mm sockets, for use on 4-6 volts D.C. Overall length: 4.3"

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $25.00

PH0840 Demonstration Induction Coil with Primary and Secondary Coils & Cylindrical Magnet.jpg

DEMONSTRATION INDUCTION COIL WITH PRIMARY & SECONDARY COILS AND CYLINDRICAL MAGNET

Code: PH0840

With primary of heavy gauge enamelled copper wire, approximate resistance 0.5 ohms wound on former 110 x 30 mm length x diameter.

Secondary coil of fine enamelled copper wire, approximately resistance 100 ohms on former 120 x 82 mm length x diameter. Both coils fitted with 4 mm sockets.

Iron core 160 x 15 mm length x diameter.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $78.00; ($69.00 special pre-order price)


RHEOSTAT

Code: PH1151F

· Portable, heavy duty educational model

· Provides a variable resistance in electrical circuits.

· Maximum current: 5 Amps

· Resistance: 11 Ohms

· Tube size: 300 x 43mm

· Sliding carriage, air cooled.

Price: $96.00


RESISTANCE UNIT 4MM

Codes: PH1143A: 1 OHM - Max. 1.0V

PH1143B: 2 OHM - Max 1.4V

PH1143C: 5 OHM - Max 2.2V

PH1143D: 10 OHM - Max 3.0V

PH1143E: 20 OHM - Max 4.0V

PH1143F: 50 OHM - Max 7.0V

PH1143G: 100 OHM - Max 10.V

A range of resistance units encased in plastic enclosure with 4mm terminals. Based on a high stability metal film element. They offer improved accuracy & robustness. Less expensive than traditional resistance coils. Accuracy 1% Suitable for PHYSICS experiments.

Price: $7.00 (each)

MAGDISC6X Magnets Neodymium disc 6mm.jpg

MAGNETS - NEODYMIUM DISC 6MM

Code: MAGDISC6X1.5 (1.5mm); MAGDISC6X2 (2mm)

· Rare Earth Disc Magnet

· Axially magnetized

· Weight: 1gm

· Width (diameter): 6.0mm

· Height: 1.5mm (MAGDISC6x1.5) and 2.0mm (MAGDISC6X2)

· Pull Force: 0.400kg (MAGDISC6x1.5) & 0.540kg (MAGDISC6x2)

· Grade: N38

· Coating: Nickel (NiCuNi)

· Gauss: 2818 (MAGDISC6x1.5) and 3495 (MAGDISC6x2)

Price: $0.90 (MAGDISC6x1.5)'; $1.20 (MAGDISC6x2)


COMPASS - 35MM

Code: EM0193-01

· Ideal for use by students

· Smooth action pocket compass

· 35mm diameter

Price: $3.35


“HODSON” MOTOR KIT

Code: EM2193-201

· Set of 2, packed into a strong jar

· Students can wind up their own electric motor and make the brushes required to run it

· The motor can run as either a DC motor from a battery or as a synchronous AC motor required from an AC power source (not supplied)

· Students obtain knowledge from winding the motor and predicting the results

· Everything is provided in the kit to assemble the motors (photo depicts motor assembled for use)

· Instructions included

· Requires 1 x D battery (not supplied)

Price: $31.95

LIQCONDAPP Liquid Conductivity Apparatus.jpg

LIQUID CONDUCTIVITY APPARATUS

Code: LIQCONDAPP

· Test the conductivity of liquids in a test tube or narrow beaker

· Can test conductivity of solids as well

· Two stainless steel wires, connected to the globe, will fit into the test tube

· Overall length: 140mm (approx.); Plate size: 80mm x 60mm x 2mm (approx.)

NOTE: Power source such as 3 xAA Batteries required. A single 1.5V battery does not supply adequate current for the globe to register the conductivity of liquids.

This apparatus can be used in conjunction with the 2 way component holders (PA0875-001) which has 2 x banana sockets & 2 x connectors to allow connections to be made to small or fragile components by standard 4mm banana plugs.

Price: $9.50

PH0927-N8 Student Cell & Porous Cup.jpg

STUDENT CELL & POROUS CUP

Code: PH0927-N8

This basic voltaic student cell set is ideal for demonstrating the characteristics of primary cells.

The set includes one plastic student cell complete with a screw-on plastic ring, two adjustable electrode holders, porous ceramic cup and eight electrodes: (1) aluminium, (1) nickel, (1) tin, (1) graphite, (1) iron, (1) copper, (2) zinc. Complete instructions are included.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $42.00; ($39.50 special pre-order price).

PH0927A - J Electrode Strips for Student Cells.jpg

ELECTRODE STRIPS FOR STUDENT CELLS 100 X 19MM (CARBON ROD 100 X 6MM)

Codes: PH0927A - Aluminium; PH0927B - Brass; PH0927C - Carbon; PH0927D - Carbon Rod; PH0927E - Copper; PH0927F - Lead; PH0927G - Nickel; PH0927H - Tin; PH0927I - Zinc; PH0927J - Iron

For student’s demonstration cell, very high quality electrodes for use with cells. Size 100 x 19 mm (except carbon rod 100 x 6mm).

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price (each): $5.50; ($5.00 special pre-order price)

PH1245N8 AC DC Motor Generator Demo Activity Model - Hand Powered.jpg

AC/DC MOTOR GENERATOR DEMO ACTIVITY MODEL - HAND POWERED

Code: PH1245N8

Learn about current and see a visual demonstration. The elegant design produces AC & DC current at the same time.

Allows students to easily compare and contrast an AC generator and a DC generator.

Activity guide included.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $129.00 ($119.00 special pre-order price)

PH1365  Planck's Constant Determination Box.jpg

PLANCK’S CONSTANT DETERMINATION BOX

Code: PH1365

This apparatus is designed to determine the approximate value of Planck’s constant using the elbow voltage in the characteristic curves of a number of LEDs.

There are 7 LEDs covering from deep blue at 470 nm to near IR 940 nm mounted on the box with sockets for voltage and current measurements. By monitoring the voltage at which each LED just begins to emit light a graph of energy input as a function of light emitted frequency can be plotted and an approximate value of Planck's constant can be deduced.

External power supply for 9 volts is required or a 9 Volts battery with suitable connecting cords can also be used.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $127.00 ea. Special pre-order price: $122.00 ea {1 - 14}; $117.00 {15+}.

PH1252 Bicycle Dynamo Assembly.jpg

BICYCLE DYNAMO ASSEMBLY

Code: PH1252

For showing slow AC on an oscilloscope or meter or for demonstrating the use of a dynamo in lighting a lamp.

This apparatus has a cycle dynamo mounted on a base. Two 4 mm. socket terminals are provided for the dynamo output, connected in parallel with an M.E.S. lamp holder and 2.5 V bulb.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $59.00


WORCESTOR CIRCUIT BOARD KIT (NUFFIELD)

Code: CIRCBRDWOR

Allows students to investigate the nature and properties of electricity. Comes with detachable battery holders which enable the construction of simple series & parallel circuits.

Consists of:

1 x Baseboard with aluminium pegs; 3 x Cell holder with phosphor -bronze connector; 20 x MES 2.5V Bulb; 10 x Bulb holder with connector; 12 X Phosphor-bronze connector; 1 x Rheostat with connector; 1 x 3.9 Ohm Resistor with connector; 1 x Diode with connector; 2 x Crocodile clips; 2 x Crocodile clips with flexible leads; 2 x switch with connector; 2 x Flexible leads with 4mm plug and crocodile clip; 2 x Soft iron nails; 1 x reel Bare copper wire SWG24; 1 x pack Pencil leads; 1 x pack Steel wool; 1 x sheet Copper foil; 1 x coil Eureka wire SWG 34; 1 x coil 2.5m PVC coated copper wire; 1 x Electrode support disc.

Activity booklet provided.

Price: $125.00

(NOTE: WE ALSO HAVE 1 KIT IN STOCK THAT HAS BEEN OPENED FOR INSPECTION. NOT USED. SPECIAL PRICE $90.00).


MOTOR CONSTRUCTION KIT

Code: EM1413-01

· High quality build / take apart unit for the demonstration of the transformation of energy and the operation of a motor

· Open structure, ideal for analysis

· Small tool included

Price: $28.50

MOTDMT Edited Catalogue.jpg

DEMOUNTABLE MOTOR KIT

Code: MOTDMT

· A mini model of a simple form of DC electric motor has a 2 pole armature wound with enameled copper wire and a permanent magnet

· The construction of the model is open for observation and investigation

· The two magnets are able to be removed for experimentation

· Wiring for hooking up to a battery source, mini spanner and screw driver are supplied with the kit

· Motor kit is stored in its own plastic box

(Power source such as 3 x AA Batteries recommended. Not included)

Price: $19.50


SIMPLE VOLTAIC CELL

Code: PH0924

Consists of a glass jar, 15cm high x 10cm diameter, with zinc and copper plates. The plates are partially immersed into the electrolyte liquid (eg. sodium chloride). The metals will react by dissolving into positive ions at different rates, resulting in a potential (voltaic) difference between the two plates.

A device to convert chemical energy into electrical energy. It is the most basic type of “wet” cell.

Price: $24.90

PH0926ABCD Plates for Simple Cells Zinc Carbon Copper Lead.jpg

PLATES FOR SIMPLE CELLS

Codes: PH0926A - Zinc; PH0926B - Carbon: PH0926C - Copper; PH0926D - Lead

Plate Size 125 x 50 mm and fitted with 4 mm socket terminals. Available in zinc, carbon, copper or lead.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price (each plate): $7.70 (zinc): $11.95 (carbon): $10.75 (copper): $7.85 (lead)

AR1070940 Westminster Electromagnetic Kit.jpg

WESTMINSTER ELECTROMAGNETIC KIT

Code: AR1070940

A comprehensive kit designed to contain all the necessary components for exploring concepts of electromagnetism, such as various types of magnets and their different arrangements and properties, working of motors, dynamos, vibrators and meters, principle of transformers, eddy current and damping etc.

Standard pack sufficient for 8 students.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $231.00; ($219.00 special pre-order price)

PH1319 Mini Motor Unit.jpg

MINI MOTOR UNIT

Code: PH1319

This small motor with a blue fan is a good fit for a variety of electronics experiments.

Operates from 1.5 to 4.5 volts DC.

Base is 3 7/8" x 2 3/4". Made from durable plastic.

Can be used with a solar cell.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $23.50 ea (1 - 10); $22.90ea (11+); ($21.50ea special pre-order price)

PH0798A Set of Metal Strips.jpg

SET OF METALS STRIPS

Code: PH0798A

Set of twelve metal strips of size 50 x 25 mm for magnetism work. Each strip is stamped with a key letter for identification.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $15.30

PH0838 Oersteds Ap.jpg

OERSTED’S APPARATUS

Code: PH0838

This demonstrates the action of electric current on a magnet.

A cobalt steel needle (75mm long) with agate bearing supported by pivot is mounted on a plastic base and surrounded by rectangular frame fitted with terminals.

(NOTE: Item supplied my differ slightly from illustration)

Price: $25.00

AR1090700 Arco Induction Coil Ruhmkorff.jpg

INDUCTION COIL (RUHMKORFF)

Code: AR1090700

Useful for the demonstration of characteristics associated with high voltage phenomena such as with Geissler tubes, spectrum analysis tubes etc. This traditional induction coil is capable of producing a spark length of up to 30mm with an input of 6-8V DC and is therefore ideal for use with vacuum tubes, eudiometers, etc. A fully adjustable trembler system is incorporated and spark suppression capacitors are housed in the base Rhumkorff commutator allows primary current to be both reversed and switched ON/OFF with make-and-break point. A pair of pointed electrodes is supplied with the instrument, the pointed electrodes having an insulating handle for adjustment of the spark gap. Low voltage input is provided via a pair of baseboard mounted colour coded 4mm sockets.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $178.00 ($172.00 special pre-order price)



SOLAR ENERGY

solar furnace.JPG

SOLAR FURNACE

Code: PH0467SF

Demonstrate the extraordinary power of the Sun. Did you know temperatures can reach more than 150 degrees C in bright sunlight?

Demonstrate this with our 31cm diameter parabolic reflector. It concentrates sunlight in a black colored copper cup.

Price:$89.00

PH0467l Mounted Solar Cell.jpg

MOUNTED SOLAR CELL

Code: PH0467L

This apparatus comprises a selenium photo-voltaic cell.

For use with the motor to demonstrate the production of electrical energy directly from light energy.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $47.50; Special pre-order price: $44.50 ea {1 - 9 units} or $42.50 ea {10+}.

PH1321 Solar Energy Kit.jpg

SOLAR ENERGY KIT

Code: PH1321

Apply knowledge of solar energy in a practical experiment. This Solar Energy Kit comprises of a solar panel housed in a plastic box, a low consumption motor with fan, a buzzer and an LED for conducing a series of solar powered activities.

Price: $78.00



HEAT ENERGY & HEAT TRANSFER


HEAT TRANSFER KIT - PACK OF 15

Code: PH1120144PK15

The Heat Transfer Kit efficiently introduces concepts of thermal energy and heat transfer to students. The aluminum heat transfer bar effectively demonstrates the migration of thermal energy between the two Styrofoam calorimeters. Comes with two thermometers specifically designed for hot and cold temperatures.

Kit Contains 15 sets each of:

2 x Styrofoam Calorimeters with lids

1 x Aluminum heat transfer bar

1 x Low range thermometer (-40 - 50 deg. C)

1 x High range thermometer (-30 - 110 deg. C).

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $289.00; Special pre-order price: $270.00

Also available as a single set:

Code: PH1120146

Price: $35.00; Special pre-order price: $32.00.

AR1060825 Arco Investigating Energy Transfer.jpg

INVESTIGATING ENERGY TRANSFER

Code: AR1060825

Study heat and light with the simplest of materials - a black can, a silver or white can and a connecting copper bar. Measure the temperature inside dark and shiny bright cans to determine the different ways light and heat are absorbed and radiated. Fill both cans with water - one with hot, one with cold - and connect them with the included energy transfer bar. Observe how the temperature of the water changes.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $25.30; ($23.50 special pre-order price)

PH0411A Leslie's Cube - Tin.jpg

LESLIE’S CUBE - TIN

Code: PH0411A

Tin plate box with 13 cm sides. The vertical faces of the box are blackened, roughened, varnished and polished respectively. The top opening is fitted with a stopper.

The apparatus is filled with water maintained at boiling point by a low Bunsen flame. Infrared sensors may be used to compare the relative radiant heat output from each of the four faces.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $25.95

PH0411B Leslie's Cube - Copper.jpg

LESLIE’S CUBE - COPPER

Code: PH0411B

Each side of the copper cube has a different surface: dull black, bright black, white and bright. The cube measures approximately 100 mm across.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $34.95



LIGHT, OPTICS, APPLIED LIGHT & COLOUR FUNDAMENTALS


LIGHT BOX & OPTICAL SET “HODSON” 12V (STD)

Code: HL2060-001

• The comprehensive kit of parts permits many experiments in basic optics and colour blending

• The banana plugs on the cables are stackable and moulded to the cable.

• The lens adjuster cannot be removed by students. The mirrors are efficient and are virtually unbreakable.

• Genuine IEC product.

For use with a 12V AC/DC power source at 2 to 3 amps (not supplied).

Price: $121.00

PH0585A Acrylic Hollow D Cell 70mm.jpg

ACRYLIC HOLLOW D CELL 70MM DIA.

Code: PH0585A

Hollow Acrylic Semi Circle for study of index of refraction. For refraction, reflection and wave demonstrations. Diameter 70 mm.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $7.50 (1 - 24); $7.00 (25+); ($7.10 {1- 24}; $6.60 {25+} special pre-order price.

PH0585B Acrylic Hollow D Cell 200mm .jpg

ACRYLIC HOLLOW D CELL 200MM DIA.

Code: PH0585B

For refraction, reflection and wave demonstrations. Diameter 200 mm.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $9.70 (1-24); $9.20 (25+); ($9.10 {1 - 24}; $8.60 {25+} special pre-order price).


LIGHT BENDER

Code: PH0587

· Light guide demonstrator displays total internal reflection. Can be used with a light box to demonstrate total internal reflection. It helps students to understand the principles of optical communications. The bottom of the bar is white to aid visibility.

· Acrylic bar 220 x 20 x 20mm

· Light can go around corners!

Price: $12.00

PH0550E Lens Holder.jpg

LENS HOLDER

Code: PH0550E

Lens holder, comprising of a metal holder with sides grooved to hold the lens or mirror. The holder is finished in matt black and is free standing for bench use.

Can slide narrow meter rulers through the slot in the base for measurement.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $7.05 (1 - 24); $6.65 (25+)

1110767 LED Array.jpg

LED ARRAY

Code: AR1110767

LED Array can be used to study the relation between light color and wavelength. Planck’s constant can also be determined by knowing voltage & the wavelength across different color LEDs.

Features :

Eleven different color LEDs with different wavelength are mounted in a vertical column.

Rotary switch is provide to select any individual LED or all together.

4mm safety sockets are provided to check the voltage across individual LED.

Input5V DC, 1.5 Amp Power Adaptor.

Price: $109.95

PH0538A Lenses 50mm Set of 6 original.jpg

LENSES 50MM - SET OF 6

Code: PH0538A

· 50mm diameter glass optic lenses

· Ground and polished surfaces

· Double convex, plano-convex, converging concave-convex, diverging concave-convex, double concave & plano-concave

· In storage case (Item supplied may vary from illustration)'

Price: $27.50

Lens Holder.jpg

LENS HOLDER

Code: LENSHOLD

· Adjustable lens holder

· Plastic

· Able to hold a 4mm thick lens that are up to a diameter of 75mm

· Height can be adjusted by up to 60mm

· Overall dimensions (approx.): 110 x 70 x 160mm

Price: $6.60

Newton's Colour Disc.jpg

NEWTON’S COLOUR DISC - HAND DRIVEN

Code: PH0582HS

200mm diameter disc contains 4 distinct quadrants, each with violet, indigo, blue, green, yellow, orange & red wedges. When stationery, the wheel consists of the separate colours described. When the wheel is set in motion, does that still hold true?

Plastic handle attaches to the centre of the wheel, which can be set to spin with an included cord.

Overall dimensions: 200 x 160mm.

Price: $20.50

PRHL1056-01 Prism - Equilateral.jpg

PRISM - EQUILATERAL

Code: PRHL1056-01

· 50mm glass prism; 60 x 60 x 60 degree angles

Price: $11.75

PRHL1706-01 Prism - Right Angle.jpg

PRISM RIGHT ANGLE

Code: PRHL1706-01

· 50mm glass prism

Price: $13.20

AR1110752 Laser Ray Kit.jpg

LASER RAY KIT

Code: AR1110752

The kit consists of the following items:

· 1 x Diode laser box: It consists of 5 independent laser modules with peak wavelength of 635mm; · 1 x Power adaptor; · 1 x Beam selector; · 1 x Human eye sheet; · 1 x Photo camera sheet; · 1 x Galilean telescope sheet; · 1 x Kepler telescope sheet; · 1 x Spherical aberration sheet; · 1 x Periscope sheet; · 1 x Hartle’s circle sheet; · 1 x Bi-convex lens no 1, 1 x bi-convex lens no. 2,; · 1 x Bi-convex lens no 3,; · 1 x Bi-convex lens no. 4,; · 1 x Bi concave lens no. 5,; · 1 x Plane convex lens r=45mm,; · 1 x Plane convex lens r=75mm; · 1 x Plane concave lens; · 1 x Concave mirror; · 1 x Convex mirror; - 1 x Plane mirror; · 1 x Rectangular slab Prism; · 1 x Optical Fibre; · 1 x Magnetic board.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $448.00; ($428.00 special pre-order price).

PH0649 Optical Bench Kit.jpg

OPTICAL BENCH KIT

Code: PH0649

This kit an optical bench that offers more enhanced set of accessories allowing the user to perform more experiments in optics.

The bench is 1 metre long and is graduated on one side.

Set comprises of :

1 Bench with ends 1 meter long; 8 pcs. Riders with tightening screw; 1 Lamp housed with halogen bulb 12 Volt, 24 Watt; 6 pcs. Lens Holder for 50 mm diameter lenses; 1 each Lens Biconvex +10,+20,+50 1 pc. Lens Biconcave -20; Set of Diaphragms; 1 Plain mirror 100 x 100 mm; 1 Translucent screen 100 x 100 mm; 1 Transparent screen 100 x 100 mm; 1 Object screen white 100 x 100 mm.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $155.00

AR1110815 Reflection & Refraction Tank.jpg

REFLECTION & REFRACTION TANK

Code: AR1110815

Protector is printed on the front of acrylic tank, to read out the angle of reflection & refraction. A laser diode with inbuilt beam spreader is supplied with the apparatus to perform the experiments of reflection & refraction.

The major advantage of the reflection & refraction tank is, the total internal reflection experiment can also be done.

Overall dimensions: 200×150x100mm

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $75.00


STROBOSCOPE-LED DIGITAL

Code: LB3806-001

· For student use

· Low voltage miniature unit, 12V AC/DC

· The LEDs provide a bright white flash

· The flash accuracy and stability is absolute

· Frequency can be adjusted from 1Hz to 500Hz

· Packed with features

Price: $308.00

AR1110800-1 Ray Track Apparatus.jpg

RAY TRACK APPARATUS

Code: AR1110800-1

Comprises a wooden board with painted white, mounted on non-skid plastic feet, and a removable turntable about 170mm in diameter with two orthogonal lines along its diameter dividing it into four equal quadrants. Just beyond the rim of turntable, a circular scale graduated 90º-0-90º-0-90º × 1º is printed. Also includes a Ray Box with a 12V, 24W bulb.

Supplied complete with a cylindrical convex lens of focal length about 75mm and two double slits, giving one wide beam slit and one each of single, triple and five slits.

Used with Ray Track Apparatus-Optical Set (AR1110800-2). Shown in photo above.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $85.95

NEWTONS DISC ON STAND-1.jpg

NEWTON’S COLOUR DISC - HAND DRIVEN

Code: PH0582A

· Demonstrates that white light may be composed of all the spectral colours by the rotation of the multi-coloured disc

· Mounted on metal stand; Hand operated, driven by belt

· 175mm multi-coloured disc

(Item supplied may vary slightly from unit illustrated)

Price: $58.00


EDUCATIONAL DIFFRACTION SLIDE

Code: PH0625

· For demonstrating the principle of the diffraction grating and the way in which its properties are dependent upon the number of lines per unit length

· Comprises of a card mount 90 x 40mm approximately with three 16 x 9mm apertures, each containing a diffraction grating replica

· The grating are of 100 lines/mm, 300 lines/mm and 600 lines/mm respectively and protected cover glasses.

Price: $61.00


DIFFRACTION GRATING 100 LINES / MM

Code: PH0624A

· 100 lines / mm; Transmission type

· 50mm x 50mm mounted in frame

Price: $38.00


HINGED MIRRORS

Code: MIR11657

· Single sided 3mm thick rigid plastic mirrors that are taped together to enable creative angled reflections; Three sets of 2 mirrors each 150mm x 100mm

· Stable, fantastic for light studies

Price: $18.50


UNBREAKABLE DOUBLE SIDED MIRROR

Code: MIRHL0976-01

· Double Sided, high quality mirror finish; Acrylic

· Both sides are protected with a peel off film and can be bent or cut easily

· Can be used in: Science experiments with light; Maths’ shape & symmetry work; creative art and craft projects

· Size of sheet: 100mm x 150mm

Price: $8.80

AR1110805 Reflection & Refraction Block.jpg

REFLECTION & REFRACTION BLOCK

Code: AR1110805

Consists of an acrylic block of 300×300×6mm and a supporting base of 300×300×25mm.

Supplied with laser diode to perform the experiments of reflection & refraction.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $101.00


PRISM - GLASS

Code: PRGL503

· 50mm long optical glass prism used to demonstrate that white light is made up of the colours of the rainbow (the spectrum)

· Each face is 28mm; Corners are ground for safety

· Suitable ages 10+

Price: $8.95


RAY TRACK APPARATUS - OPTICAL KIT

Code: AR1110800-2

Optical Set for Ray Track Apparatus (Code: AR1110800-1). One each of rectangular, semi-circular, right angled triangular-90°×45°×45°, trapezoidal, biconvex and biconcave'.

(NOTE: Optical Set is illustrated with the RAY TRACK APPARATUS)

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $107.00; ($102.00 special pre-order price).



PROPERTIES OF LIQUIDS


CATCH BUCKET

Code: PH0119D

· Aluminium vessel used for volumetric displacement of liquid experiments

· 100 x 80mm; With handle

· Should be used in conjunction with a displacement vessel (overflow can) for collecting liquid from the spout of the overflow can.

Price: $6.60


DISPLACEMENT VESSEL

Code: MS0618-01

· Metal displacement vessel with spout for specific gravity experiments

· Size: 115mm x 50mm (approx.)- Spout 40mm long (approx.)

· Holds approx. 200ml of water

Price: $6.60

AR1020240 Arco Density Sphere.jpg

DENSITY SPHERE

Code: AR1020240

Demonstrates the dependence of density of a liquid on the temperature. Comprises a hollow copper sphere, with a sealed mouth, Carefully adjusted to float in cold water and sink in the hot water

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $37.50 ea (1 - 10); $36.90 ea (11+)

AR1020340 Arco Equality of Pressure in Liquids Pascal's Law Syringe Glass.jpg

PASCAL’S PRINCIPAL DEMONSTRATOR

Code: AR1020340

This apparatus is used to demonstrate that the liquid transmits equal pressure in all directions.

The apparatus comprising a glass cylinder provided with a piston plunger on one end and terminating in a spherical glass bulb on the other end. The bulb has small holes around its surface. On pushing the plunger inside with the apparatus filled with water, water is ejected with equal force from all the holes.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $11.50 ea; Special pre-order price: $10.00 ea {1 - 9}; $9.50ea {10+} .

AR1020360 Pascal's Ball Pascal's Law Syringe Metal.jpg

PASCAL’S BALL, METAL

Code: AR1020360

All metal construction provides rigidity, sturdiness and durability to the apparatus. Comprises a removable spherical metal bulb mounted at one end of the cylindrical barrel with piston plunger at the other end. The spherical bulb has a number of holes on its surface with small brass nozzles projecting out. All metal parts either well painted or plated. When filled with water, pushing in the plunger makes water to eject from all the nozzles with equal force.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $48.95; Special pre-order price: $44.95.

PH 0200B.jpg

LIQUID LEVEL APPARATUS

Code: PH0200B

· Stunning demonstration

· Demonstrates Pascal’s theorem of communicating vessels

· Set of 4 tubes on plastic stand

· Shows that the level of communicating vessels is constant irrespective of the size or shape of the vessels.

Price: $21.50

PH0202A Capillary Tubes Apparatus.jpg

CAPILLARY TUBES APPARATUS

Code: PH0202A

· Demonstrates relationship between capillary pressure & the bore diameter of the capillary tubes

· Comprises of a metal frame arrangement whose base is like a trough;· The upper part of frame supports six capillary tubes of different bore; Fill trough with water and the difference in heights of the resulting columns of water in the tubes is apparent

· Overall frame height 90mm; Capillary tube length 150mm

Price: $31.95

AR1020370 Arco Pascal's Law Apparatus.jpg

PASCAL’S LAW APPARATUS

Code: AR1020370

This apparatus is used to demonstrate the Pascal's Law that pressure exerted by a liquid in an enclosed space is equal in all directions.

Comprises a spherical glass bulb (with holes) with its neck supported horizontally and is connected to a vertically mounted 50ml plastic syringe through a flexible rubber tubing. Complete apparatus mounted on a plastic base.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $33.50; Special pre-order price: $30.50

AR1021245 Arco Harbottle.jpg

HARBOTTLE

Code: AR1021245

The Harbottle helps students understand the concept of fluid pressure and pressure reduction. It is a spherical glass container with a balloon stretched over its opening and a hole in the flattened base that is fitted with a rubber stopper.

See students be amazed when they observe that the balloon remains inflated inside the bottle even though it is not tied off or sealed.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $12.50; Special pre-order price $11.50.



DYNAMICS - SPRINGS, PENDULUMS & PULLEYS


HOOKE’S LAW-SPRINGS -

NON-PROPORTIONAL- SET OF 5

Code: MF1918-001

· This set of 5 springs, with their chosen diameters and lengths, together with the choice of their wire thicknesses, make them very suitable for experiments relating to “Hooke’s Law

· This set contains the following springs:

• 1x Tension Spring, 6.2 x 320 mm diameter x length x 1.02 mm. diameter wire

• 1x Tension Spring, 6.2 x 210 mm diameter x length x 1.02 mm. diameter wire

• 1x Tension Spring, 7.8 x 70 mm diameter x length x 0.90 mm. diameter wire

• 1x Tension Spring, 9.2 x 300 mm diameter x length x 0.71 mm. diameter wire

• 1x Tension Spring, 14.5 x 300 mm diameter x length x 0.88 mm. diameter wire.

Price: $23.10

PH0325 Helical Spring & Mass Set.jpg

HELICAL SPRING & MASS SET

Code: PH0325

· Used to illustrate Hooke’s Law

· Consists of 20cm steel spring with hooks on both ends

· Masses: 1 x 2kg, 1 x 0.5kg, 1 x 237g with hooks on both ends.

Price: $69.30

PH0305 Pulley Demonstration Set Student's.jpg

PULLEY DEMONSTRATION SET - STUDENT’S

Code: PH0305

Designed to demonstrate various concepts associated with pulleys and their configurations. Demonstrate multiple configurations simultaneously or concentrate on one topic.

Built to last for years in the classroom with a sturdy metal base and quality-made steel rods. Easy to use, designed for students learning the basics of mechanical advantage with pulley applications. The variety of included pulleys and accessories make it the ideal pulley demonstration tool.

Set includes:

- Pulleys - (8) single, (2) double sheave, ball bearing frictionless pulleys

- Wooden base (20 x 15 cm) fitted with one vertical rod (61 cm x 12.5 mm) and one horizontal rod (20 cm x 9.5 mm) with clamp

- (6) Collars with hook; - (1) Right angled clamp; - (1) Wheel & axle; - Cord - 2 rolls; - (1) Tommy bar to tighten vertical rods

- Brass hooked mass set (1x10g, 2x20g, 1x50g, 1x100g, 2x200g, 1x500g, 1x1000g)

- Instructions included.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $332.00 (Available by pre-order only)

PH0306F Pendulum Bobs with Hooks Set of 3.jpg

PENDULUM BOBS WITH HOOKS - SET OF 3

Code: PH0306F

Comprising a set of 3 solid spheres. One each of brass, copper & iron having diameter of 25 mm with a small ring for suspension.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020

Price: $17.20; ($14.00 {10+ sets} special pre-order price)


HOOKE’S LAW-SPRINGS – PROPORTIONAL - SET OF 6

Code: MF1918-101

· This set of 6 springs with their chosen diameters and lengths, together with the choice of wire thicknesses, make them very suitable for experiments relating to “Hooke’s Law”

· The ‘proportional set’ have diameters and lengths in convenient ratios to one another

· All 6 springs are tension springs with 'eye' each end

· This set contains the following springs:

• 1x Tension Spring, 10 x 150 mm diameter x length x 0.56 mm. diameter wire

• 1x Tension Spring, 10 x 300 mm diameter x length x 0.56 mm. diameter wire

• 1x Tension Spring, 10 x 150 mm diameter x length x 0.71 mm. diameter wire

• 1x Tension Spring, 10 x 300 mm diameter x length x 0.71 mm. diameter wire

• 1x Tension Spring, 15 x 150 mm diameter x length x 0.71 mm. diameter wire

• 1x Tension Spring, 15 x 300 mm diameter x length x 0.71 mm. diameter wire.

Price: $23.10

PH0323SP3 Multi Spring Hook's Law App.jpg

MULTI SPRING HOOKE’S LAW APPARATUS

Code: PH0323SP3

This design allows students to investigate hooks law for single spring, series and parallel spring combinations.

The apparatus is supplied complete with a robust stand, rod and 3 springs.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $79.50

PH0309 Pendulums on Stand.jpg

PENDULUMS ON STAND

Code: PH0309

Heavy metal stand with a meter scale mounted on a vertical rod can hold three pendulums of 5 cm apart with points for suspension of cords.

Three 2.5 cm pendulum bobs of wood, iron and steel are suspended from a common hanger mounted on a vertical rod screwed to a heavy metal stand. A meter scale and a sliding index with projecting piece is provided. The sliding index can control the length of the first cord.

Zero of meter stick is placed at the bottom and when the center of the pendulum is placed opposite this point, the length of the pendulum is read directly from the position of the slider.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $62.90; ($57.90 special pre-order price)


PULLEY - IN-LINE - PLASTIC

Codes: PUPA80 (Single); PUPA81 (Double); PUPA80A (Triple)

Economical pulleys perfect for students use. They come with steel frames, brass axles, wide hubs and rigid plastic free-running sheaves. Sheaves on single axle pulleys are 50 mm in diameter. All pulleys feature steel hooks at each end.

Sold separately. (Photo is of the Double-In-Line Pulley (PUPA81)

Price: $3.85 (Single); $4.95 (Double); $6.05 (Triple)

PUCLAMP70 Pulley with universal clamp large.jpg

PULLEY WITH UNIVERSAL CLAMP – LARGE

Code: PUCLAMP70

Large 70mm light alloy pulley with universal bench clamp.

Can be clamped onto edge of bench upto 3.75cm thick, or screwed to flat surface or on 13mm diameter support rod.

(Item supplied may differ slightly from illustration)

Price: $27.50

PH 0281.jpg

PULLEY – PLASTIC, BALL BEARING TANDEM

Codes: PUPH281A (Single); PUPH281B (Double); PUPH281C (Triple)

Open sided frame, with hooks at each end carrying three ball bearing pulleys with 25mm, 38mm & 50mm diameter. The open side frame greatly facilitates stringing up as no 'threading' is involved.

Sold separately.

Prices: $5.00 (Single); $8.00 (Double); $11.00 (Triple)

PH0322 Hookes Law Apparatus Single Spring.jpg

HOOKE’S LAW - SINGLE

Code: PH0322

Measure and prove that the stretch of a spring is proportional to its load. You can also determine harmonic motion by counting the oscillations.

Illustrated instructions included.

Complete Kit.

Price: $69.50


PENDULUM CLAMP

Code: PENDUCLP

· Makes it easy to simultaneously demonstrate or test the properties of simple harmonic motion in physics labs or classrooms

· Three screw clamps can securely and individually be used to attach weights with string

· For use on support rods up to 16mm in diameter to hang weights or pendulums

· Overall length (approx.): 28.5 x 3.75 x 3.1cm

Price: $18.10

MF430x-001 Brass Hooked Weights IEC.jpg

SET OF 9 WEIGHTS WITH CARRIER - BRASS

Code: MF4303-001 (10g); MF4300-001 (50g); MF4301-001 (100g)

· Set of 9 brass slotted weights on carrier. Choice of 10g, 50g or 100g weight set

· High quality, genuine IEC product

Price: $34.10 (10g); $56.10 (50g) & $77.00 (100g)

PH0109PCB Drilled Ball Set of 12 Plastic Box.jpg

DRILLED BALL SET OF 12 IN PLASTIC BOX

Code: PH0109PCB

Perfect for pendulum experiments. It’s a multi-purpose set ideal for pendulum experiments but can be used to meet a variety of lab needs.

Set includes 6 balls each 25 mm in diameter. Contains two balls each of Wood, Aluminium, Steel, Cork, Brass and Lead. Each ball is drilled with 3 mm diameter hole.

Supplied in plastic box.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $67.00; ($62.00 pre-order price)

PH0324 Elastics Materials Kit.jpg

ELASTICS MATERIALS KIT

Code: PH0324

Contains various materials such as springs, rubber blocks, wire, rubber cord, tube etc., provided for class experiments to explore ‘elasticity’.

Kit comprises 2 latex foam blocks, 130 x 50 x 50 mm square, 4 elastic cords with eyelets, 4 soft rubber erasers, one 900 mm length of valve rubber tubing, 40 g reels of bare copper wire 0.28 mm and 0.45 mm diameter, 2 wide steel strings of 4½ turns 50 mm diameter and 25 pcs. of expandable steel springs for testing beyond the elastic limit, with ends bent to form hooks.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $43.00 each kit; ($40.50 (1 - 10 kits); $39.00 (11+ kits) pre-order price)

MF2290-00 Pendulum Bobs - Brass - 3 Diams.jpg

PENDULUM BOBS - BRASS - 3 DIFFERENT DIAMETERS

Code: MF2290-00

· Set of 3 brass pendulum bobs; Genuine IEC products

· Each bob has a 1.5mm diameter hole drilled right through the diameter with one side made larger so that a knot in a cord can be pulled into the larger hole to hold firmly and also be out of sight. Pack contains the following:

1 x Brass bob: 25mm diameter; 1 x Brass bob: 20mm diameter; 1 x Brass bob: 12mm diameter

Price: $14.30

WTHKD Weight Set Hooked - Set of 9.jpg

WEIGHT SET HOOKED - SET OF 9

Code: WTHKD

· Cast Iron with black enamel finish weights. They are hooked at one end and the other end has a recessed bar so that weights are can be hung from the bottom. 10g weight does not have bar on the bottom. Comes complete with plastic tray to store weights.

1 x 10g; 2 x 20g; 1 x 50g; 1 x 100g; 2 x 200g; 1 x 500g; 1 x 1000g

Price: $86.90

PH0109 Drilled Ball Set of 6.jpg

DRILLED BALL SET OF 6

Code: PH0109

Perfect for pendulum experiments. It’s a multi-purpose set ideal for pendulum experiments but can be used to meet a variety of lab needs. Set includes 6 balls each 25 mm in diameter.

Contains one ball each of wood, aluminium, steel, copper, brass and lead. Each ball is drilled with 3 mm diameter hole.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $30.50; ($28.50 special pre-order price)

PH0302A Cords Suspension Nylon.jpg

CORDS SUSPENSION - NYLON

Code: PH0302A

Nylon cord. Suitable for small pulley system & pendulum. Length 30 m approx.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $9.20

PH0302B Cords Suspension Cotton.jpg

CORDS SUSPENSION - COTTON

Code: PH0302B

Cotton twin cord. Suitable for small pulley system & pendulum. Length 30 m approx.

PRE-ORDER OF THIS ITEM IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $6.70



GENERAL PHYSICS


CENTRE OF GRAVITY APPARATUS

Code: 1030500

· Used to demonstrate the geometrical center of gravity of two-dimensional object

· The center of gravity of a freely suspended two dimensional object always lies along the line drawn vertically downward from its point of suspension

· Comprises of a clear perspex rod mounted on a base with a suspension screw at the top and four laminas of clear acrylic - one each of circular, triangular, square and trapezoidal

· Each lamina has suspension holes along their periphery

· The point of intersection of lines drawn from point of suspension of 2 or more holes of a lamina gives center of gravity of that 2-dimensional lamina

· Suitable for laboratory use only

· Suitable for ages 13+.

Price: $28.35

PH0203AG Spheres Steel Ball Bearings 25mm.jpg

25MM SPHERES, STEEL BALL BEARINGS

Code: PH0203AG

High quality 25mm steel ball bearings. Can be used for a variety of experiments.

Quantity per pack: 5.

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $10.45

AR1030680-3 Arco Set of Spheres, Solid without plastic tray.jpg

SET OF SPHERES - 25MM

Code: AR1030680-3

Ideal for collision experiments and pendulum demonstrations and can also be used to meet a variety of laboratory needs. Solid spheres are also suitable for density/volume experiments. The set includes 6 balls of 25mm diameter each of different materials-one each of wood, aluminum, steel, copper, brass & lead. The set comes packed in a plastic box.

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $30.50; ($28.50 special pre-order price)

PH0108R Cubes for Density Investigation with Hook 20mm Set of 7.jpg

CUBES FOR DENSITY INVESTIGATION WITH HOOKS 20MM

Code: PH0108R

Density Cubes, Set of 7 Metals in Plastic Case with Hooks and Element Stamp.

20mm sides - Iron, Copper, Aluminum, Brass, Tin, Zinc, Lead - For use with Density, Specific Gravity, Specific Heat Activities.

Supplied with manual.

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $67.00; ($62.00 special pre-order price)

PH0103 Cone Dissectable Eisco.jpg

CONE DISSECTIBLE

Code: PH0103

This cone is made of polished hardwood with four different sections. It can be dissected into 5 parts.

Hardwood, polished, 24 cm height and 15 cm base dia. Four different sections: circle, ellipse, parabola and hyperbola held together by a pin and easily taken apart for demonstration.

Price: $59.00

PH00347DSSECO Hooked Weights Stainless Steel.jpg

HOOKED WEIGHT SETS - STAINLESS STEEL (METRIC GRAMS)

Code: PH0037DSS

Stainless Steel Hooked weights. Set of 9 weights, 10-1000 g in wooden block.

Stainless Steel hooks at both ends. Recessed bottoms to enable the weights to be hooked together. The bottom is flat when placed on a flat surface.

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $175.00; ($168.00 special pre-order price).

Code: PH0037DSSECO

Same as PH0037DSS but with weights of 1 kg and 500 g in steel.

Price: $131.00; ($121.00 special pre-order price)

AR1010230 Arco Density Rods Set Different Material.jpg

DENSITY RODS SET - DIFFERENT MATERIAL

Code: AR1010230

Density Rods Set, Comprising 12 cylinders of different material and of different lengths (38mm-60mm) but of same diameter 12.5mm.

All density rods are placed in a square shaped wooden block. Copper Rod, Brass Rod, Acetyl Rod, Rubber Rod, Acrylic Rod, Aluminum Rod, Polypropylene Rod, PVC Rod, Nylon Rod, Oak Rod, Maple Rod, Walnut Rod.

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $48.85

AR1130260 Alpha Scattering Apparatus.jpg

ALPHA SCATTERING APPARATUS

Code: AR1130260

A low cost apparatus for the demonstration of the Rutherford scattering by means of a gravitational analog of inverse square law repulsion.

Comprises a wooden launching lamp about 300x50x105mm (L x W x H) with a guiding groove running down its curved front face along its length and index marks at 40,60, 80 and 100mm height above the base that provides 4 pre-determined launching heights. Also included is a spun aluminium hill about 280mm diameter and 60mm height along with a 19mm steel ball.

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $44.50



WEATHER & METEOROLOGY


ANEMOMETER - CUP

Code: 1055043

· Wind speed anemometer working model

· Mounted on a low friction bearing and consisting of 3 black plastic & 1 red plastic cup

· 210mm x 180mm (h)

· Anemometer is sensitive at wind speed of 1.5km/h; Student can determine the wind speed quantitatively by counting the number of rotations

Price: $32.95


FITZROY’S STORM GLASS

Code: HJ6185

· Predict the weather!

· The storm glass was popularised by Admiral Robert Fitzroy after his historic voyage on the HMS Beagle

· 28cm tall

Price: $28.00

Anemometer ANEMOLCD.jpg

ANEMOMETER LCD WIND SPEED GAUGE

Code: ANEMOLCD

Wind speed gauge with LCD.

Measures maximum and average air velocity; temperature and wind chill factor.

Displays Beaufort scale.

Air Velocity Range: 0-30 m/s; 0-55 Knots; 0-90km/h; 0-65mph.

Operating temperature: -10°C to +45°C

Operating humidity: Less than 90%RH

Current consumption: 3mA (approx.).

Manual / Auto power shut off.

Battery: CR2032 3.0V (included)

(Model or colour supplied may vary from illustration).

Price: $25.00



PROPERTIES OF GASES, AIR PRESSURE & AIR RESISTANCE

PH0145A Boyles Law Simple Form.jpg

BOYLE’S LAW - SIMPLE FORM

Code: PH0145A

· Apparatus to demonstrate Boyle’ law

· Graduated plastic syringe mounted on wooden block & lubricated piston of the syringe mounted on another platform

· Different weights can be placed (stacked) on the top to measure the pressure volume

Price: $33.50


MAGDEBURG HEMISPHERE

Code: PH0171A

· Extra large; Magdeburg Hemispheres have been used for centuries and is used to illustrate the force of atmospheric pressure.

· Tough Plastic; Secure o-ring seals; 11cm diameter; 2 way valve for easy release and operation

Price: $61.50


GUINEA & FEATHER APPARATUS

Code: PH0161

· Acrylic tube - 100cm (long) x 44mm (outer dia.) with two rubber bungs, one carrying stopcock and 60cm long tubing to connect to vacuum pump

· Used to show how air resistance affects a falling object

Price: $96.80

PH0156E Set of Pump Plate and Bell Jar Acrylic.jpg

SET OF PUMP PLATE & BELL IN JAR ACRYLIC

Code: PH0156E

A complete set of pump plate machined (PH0156b) and bell jar (PH0176CN8).

Made of aluminium metal, with tube for connection to pump and stopcock for air regulation on central pillar, supplied with a rubber seal which facilitates sealing in bell jar experiments. Mounted on painted heavy tripod base.

A new improved Acrylic Bell Jar of size 25 x 14 cm compatible with the pump plate. The bottom flange is ground flat to ensure a perfect seal. Electric bell is mounted for sound in vacuum experiments. Operates on 4-6V AC/DC.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $191.50

PH0176CN8 Bell in Vacuum Acrylic.jpg

BELL IN VACUUM - ACRYLIC

Code: PH0176CN8

Demonstrate that sound requires air to travel through with the Bell in Vacuum Jar set. Slowly decrease the air inside and hear the sound disappear. Electric bell operates on 4-6V DC.

Includes: (1) Bell Jar, (1) Electric Bell, (1) Rubber cork with terminals.

Requires a vacuum pump (not included).

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $67.50 each; ($63.50 each {1- 9 }; $61.50 each {10+} special pre-order price)

PH0166B Vacuum Pump With Pump Plate.jpg

VACUUM PUMP WITH PUMP PLATE

Code: PH0166B

This is an integral system with the pump plate & hand vacuum pump. The plate comes with a rubber seal which facilitates sealing in bell jar experiments. The plate can be used with electric vacuum pumps also. A rubber seal is provided for copper pump plate.

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $164.50; ($160.50ea {1 - 9 units}; $156.50 {10+} special pre-order price)


BOYLE’S MARIOTTE LAW

Code: 1020970

· Pressure/Volume relationship of air at constant temperature

· A graduated (0-300) cm3 cylinder with closely fitting piston is connected to a pressure gauge by a narrow tube to minimize the dead volume

· Cylinder is made of transparent material to see the working process inside

· Pressure inside the cylinder can be adjusted by rotating the knob connected to the piston via threaded shaft

· A gas tap allows the cylinder to communicate with the outside air to adjust the mass of air enclosed

· The pressure can directly read out from a big size pressure gauge circular dial, graduated in (0-3.4) x 105Pa.

Price: $110.00

PH0171 Magdeburg Hemisphere Rubber.jpg

MAGDEBURG HEMISPHERE - RUBBER

Code: PH0171

· Demonstrates air pressure without a vacuum pump. Place the edges of the two hemispheres together and squeeze to force out the air between them.

· Rubber; 7.5cm diameter

· Each hemisphere has 2 release posts and 2 finger tug handles

Price: $13.00

AR1020910 Arco Boyle's Law.jpg

BOYLE’S LAW

Code: AR1020910

This apparatus consists of a 29 mm dia. graduated cylinder with a screw plunger.

Cylinder acts upon a manometer through a narrow passage. 60mm dia. manometer scale is from -1000 to 3000 hPa with 50hPa interval.

Can read the gas’s temperature in the cylinder by digital thermometer in °C.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $215.00

PH0167 Vacuum Pump Hand Operated.jpg

VACUUM PUMP - HAND OPERATED

Code: PH0167

Economical pump features a gauge in cm and inches, Hg displaces 725 ml of air. Pump rate of 15 ml Clear tubing is 60cm with 6mm inner diameter.

Experiment with air pressure and atmosphere, vacuum filtering andcheck for leaks. This economical pump features a gauge in cm and inches, Hg displaces 725 ml of air. Pump rate of 15 ml Clear tubing is 60cm with 6mm inner diameter.

PRE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $125.00; ($115.00 special pre-order price)

PH0177 Bell in Vacuum Economy.jpg

BELL IN VACUUM - ECONOMY

Code: PH0177

Fitted in acrylic jar of size 20 x 10 cm and fitted with electric buzzer.Operates on 3-6 V DC.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $43.80; ($39.80ea special pre-order price)

PH0156B Pump Plate Machined 200mm dia..jpg

PUMP PLATE MACHINED 200MM DIA.

Code: PH0156B

Made of aluminium metal, with tube for connection to pump and stopcock for air regulation on central pillar, supplied with a rubber seal which facilitates sealing in bell jar experiments. Mounted on painted heavy tripod base. Diameter 200 mm.

LOW IN STOCK

MORE STOCK AVAILABLE IN LATE JANUARY 2020. PREE-ORDER OF THESE ITEMS IS NOW AVAILABLE UNTIL 30TH SEPTEMBER.

Price: $137.00; ($130.00 special pre-order price).



ELECTRIC CIRCUITS COMPONENTS


SWITCH – ROCKER

Code: SWRCKD

Rocker-type switch

SPST (“ON-OFF”)

100mm x 60mm x 60mm; with 2.5mm plastic housing on terminals suitable for both banana plugs and alligator clips. Suitable for low voltage electric circuit experiments in Physics classes.

Price: $5.50

SWCONKEY Contact Key Switch - Single.jpg

CONTACT KEY SWITCH - SINGLE

Code: SWCONKEY

Provides momentary contact when pressed down in electrical circuits which are normally open.

Silver plated points. Insulated press knob. Plated spring arm & connecting strip. Base includes two 4mm socket binding post terminals.

Suitable for Physics experiments

(Item supplied may vary slightly from photo).

Price: $9.90


ALLIGATOR CLIPS

Code: ALLICLIP

Pack contains 5 red and 5 black alligator clips with insulated sheath.

Price: $5.05 (1-4 packs); $4.73 (5-19 packs); $4.36 (20+ packs)


SWITCH – KNIFE TYPE

Code: SWKNF

Knife type switch. Single pole, single throw (SPST).

100mm x 35mm x 30mm; with 2 terminals suitable for both banana plugs and alligator clips. Suitable for low voltage electric circuit experiments in Physics & Primary School science classes to control the flow of electricity in a circuit.

(Item supplied may vary slightly from photo).

Price: $6.50

Scorpio Technology stocks a variety of switches to suit your needs. Please see our Product Catalogue for a comprehensive listing.

ALLIWIRES 3.JPG

ALLIGATOR CLIP WITH WIRE

Code: ALLIWIRES12

Alligator clips with 250mm wire – 6 colours

Price: $10.95 (1-4 packs); $10.51 (5-19 packs); $10.08 (20+ packs)

ALLICLIPISR Alligator Clip Insulated Shank Red.jpg

ALLIGATOR CLIPS - INSULATED SHANKS

Code: ALLICLIPISB (Black); ALLICLIPISR (Red)

Alligator clips with screw. Overall length approx. 75mm.

Black or red. Pack of 10 (Specify colour: red or black)

Price per pack of 10: $8.10


BANANA PLUGS - 4MM

Code: BAPLBK4A (Black); BAPLG4 (Green); BAPLR4A (Red); BAPLY4 (Yellow)

Side stacking – 4mm stem; Banana Lead Connectors – Stackable.

Available in black / green / red / yellow (specify colour & code when ordering). Pack of 10

Price: $8.50



BANANA PLUGS - PIGGY BACK - 4MM

Code: BAPLPBBK4 (Black); BAPLPBR4 (Red)

Piggy Back Style - Another banana plug can be inserted into the back of the plug; 4mm terminals (dia.)

Red or Black

Price: $1.95 (each)

BHCLIP Clip on battery holder Website edited.jpg

CLIP-ON BATTERY CONNECTOR

Code: BCLIP

Battery clip with wires fits 9V battery. Pack of 5.

Price per pack of 5: $3.19 (1-4 packs); $2.99 (5-9 packs); $2.80 (10-19 packs); $2.68 (20+ packs)


BATTERY HOLDER – 1AA

Code: BH1AA

Battery holder with wires fits 1 x AA Battery. Pack of 5.

Price per pack of 5: $5.10 (1-4 packs); $4.99 (5-9 packs); $4.84 (10-19 packs); $4.54 (20+ packs)


BATTERY HOLDER - 3AA

Code: BH3AA

Battery holder with wires fits 3 x AA batteries. Pack of 5.

Price per pack of 5: $5.90 (1-4 packs); $5.72 (5-9 packs); $5.33 (10-19 packs); $5.14 (20+ packs)

4AA-battery-holder-with-switch edited.jpg

BATTERY HOLDER - 4 X AA - FLAT

Code: BH4AAF

Battery holder with cover, wires & On-Off switch fits 4 x AA batteries. Pack of 5.

Price per pack of 5: $14.12 (1-4 packs); $12.95 (5-9 packs); $11.87 (10-19 packs); $10.88 (20+ packs)

BH6AA Battery Holder 6xAA Catalogue edited.jpg

BATTERY HOLDER - 6AA

Code: BH6AA

Battery holder with wires fits 6 x AA batteries. Pack of 5.

Price per pack of 5: $7.42 (1-4 packs); $6.87 (5-9 packs); $6.43 (10-19 packs); $6.26 (20+ packs)

BH1D Battery Holder 1D without wires.jpg

BATTERY HOLDER - 1 X D

Code: BH1D

Battery holder with wires fits 1 x D cell battery. Pack of 5.

Price per pack of 5: $7.50 (1-4 packs); $7.20 (5-9 packs); $6.91 (10-19 packs); $6.63 (20+ packs)

BHLIT Lithium Ion Battery Holder.jpg

BATTERY HOLDER - LITHIUM ION

Code: BHLIT

Fits 1 x Lithium Ion Battery. No wires. Pack of 5.

Price per pack of 5: $10.10 (1-4 packs); $9.42 (5-9 packs); $8.93 (10-19 packs); $8.80 (20+ packs)

BUZZERMIN3 Mini Buzzer 3V.jpg

MINI BUZZER 3V

Code: BUZZERMIN3

Piezo Buzzer 91DB

3-16VDC; Dimensions (approx.): 33mm (l) x 22mm (w) x 10mm (h)

Mounting hold centres: 30mm (screws not supplied).

Price: $3.14

BUZZERMIN5 Mini Buzzer 5V.jpg

MINI BUZZER 5V

Code: BUZZERMIN5

Mini Buzzer 5 - 12V

Dimensions (approx.): 33mm (l) x 16mm (w) x 15mm (h). Screw holes allow for mounting (screws not supplied).

Price: $3.86

GLOMES6.3P 6.3V MES screw light bulb  Website edited.jpg

GLOBES - MES

Codes: GLOMES6.3P (6.3V); GLOMES6.0 (6.0V); GLOMES1.2)

MES light bulb 6.3V, 0.25A. Pack of 10.

MES light bulb 6.0V, 0.5A. Pack of 10.

MES light bulb 1.2V, 0.3A. Pack of 10.

Price: $7.73 (Pack of 10)

BULB25 2.5V Globe 25 pack.jpg

LIGHT BULBS - 2.5V

Code: LIGBULB25

2.5V, 0.5A torch bulb. Pack of 25

Price: $13.85 (1 pack); $24.10 (2 packs)


HOOK UP WIRE - 10 METRES

Code: WIREHU10

Size: 21 / 0.08 (approx.)

Available in multiples of 10 metre lengths in the following colours: Black (WIREHUBK10); Red - (WIREHUR10); Blue - (WIREHUBL10); Green -(WIREHUG10); Yellow - (WIREHUY10); Orange - (WIREHUO10); Brown - (WIREHUBR10); & White - (WIREHUW10).

Please specify colour & length when ordering. If no colour is specified, black will be supplied.

Price: $2.88 (per 10 metres)

BANSOCMT Banana Plug Panel Mount Socket - 4mm.jpg

BANANA PLUG PANEL MOUNT SOCKET - 4MM

Code: BANSOCMTBK (Black); BANSOCMTR (Red)

4mm Panel Mount Sockets to suit Banana plugs.

4.0mm (I.D.); 11.3mm (O.D.); 16.5mm (length)

Black or Red

Price: $0.65 (each)


BANANA PLUG WITH WIRES (SET OF 2)

Code: BAPLW2

Red & black side stacking 4mm stem banana plugs to stacking 4mm stem banana plugs with leads.

Price: $5.40 (per pair)


BATTERY HOLDER – 9V - FLAT

Code: BH9VF

Battery holder with cover and wires fits one 9V battery. With On-Off switch. Pack of 5.

Price per pack of 5: $13.27 (1-4 packs); $12.49 (5-9 packs); $11.73 (10-19 packs); $10.98 (20+ packs)

BH2AA original.jpg

BATTERY HOLDER - 2AA

Code: BH2AA

Battery holder with wires fits 2 x AA batteries. Pack of 5.

Price per pack of 5: $5.22 (1-4 packs); $5.11 (5-9 packs); $4.84 (10-19 packs); $4.73 (20+ packs)


BATTERY HOLDER - 2AA - FLAT

Code: BH2AAF

Battery holder with cover, wires & On-Off switch fits 2 x AA batteries. Pack of 5.

Price per pack of 5: $12.61 (1-4 packs); $11.56 (5-9 packs); $10.59 (10-19 packs); $9.70 (20+ packs)

Battery Hold 4AA Catalogue.jpg

BATTERY HOLDER - 4AA

Code: BH4AA

Battery holder with wires fits 4 x AA batteries. Pack of 5.

Price per pack of 5: $6.56 (1-4 packs); $6.39 (5-9 packs); $5.85 (10-19 packs); $5.60 (20+ packs)

BH2C Battery Holder 2C Website edited.jpg

BATTERY HOLDER - 2C

Code: BH2C

Battery holder with wires fits 2 x C batteries. Pack of 5.

Price per pack of 5: $8.79 (1-4 packs); $8.29 (5-9 packs); $7.88 (10-19 packs); $7.71 (20+ packs)

BHSTKD Stackable Battery Holders.jpg

BATTERY HOLDER - D - STACKABLE

Code: BHSTKD

Fits 1 X D Battery; Stackable; In Series & Parallel Circuits; No Wires

Price: $3.50 (each)

AR1090100 Arco Commutator (MIP Reversing Key).jpg

COMMUTATOR (M.I.P. REVERSING KEY)

Code: AR1090100

For use in circuits, where a rapid changeover of polarity is required. The switch comprises a rotatable spring loaded beam of insulating plastic with two brushes each connected to 4mm socket terminals.

The brushes and contact strips are arranged on the beam and base respectively so that when beam is rotated from one side to other, the polarity of connections is reversed. All brushes and contact strips of laminated phosphor bronze brushes ensuring good contact and long life.

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $19.50 ea (1 - 10); $18.80 ea (11+)

BULBHBASE Bulb holder round.jpg

BULB HOLDER ROUND BASE

Code: BULBHBASE

Miniature bulb holder with round base for 2.5V or 6V MES bulbs. Pack of 10.

Price: $12.88

BULBH25  Bulb Holder.jpg

BULB HOLDER

Code: BULBH25

Light bulb holder for screw mounting bulb. Pack of 25.

Price: $10.17 (1 pack); $20.06 (2 packs)


GLOBE HOLDER – MES

Code: BULBPH1028B

Mounted on stable base with terminals. Modular. Globe included.

(LIMITED STOCK).

Price: $7.00

BBRDST Bread Board & Jumper Wire Set.jpg

BREAD BOARD & JUMPER WIRE SET

Code: BBRDST

This Bread Board set is an ideal tool for carrying out small Electronic / Electrical experiments.

It provides the following:

- 1600 spring loaded points which are useful for fixing the components such as IC'S, Transistors, Resistances, Diodes & Capacitors etc.

- Interconnecting columns for supply & common / earth points.

- Three 4mm Sockets are mounted on PCB with additional pins for connections. These sockets are primarily used for (+ve, -ve & Common) Power Supply.

- Set of 150 wires (Singe Strands) of different lengths & 10 nos. with connector on one side (Pin on one side & Female Connector on other side.)

AVAILABLE BY PRE-ORDER ONLY UNTIL 30TH SEPTEMBER. EXPECTED ARRIVAL LATE JANUARY 2020.

Price: $68.00 ea (1 - 14); $64.00 ea (15+)

PA0875 Component Holders IEC.jpg

COMPONENT HOLDERS

Code: PA0875-001 (2 way); PA0875-010 (3 way)

Genuine IED products

Strong and convenient method of attaching small and difficult to handle components to a set of 2 or 3 4mm banana sockets to allow connections to be made to small or fragile components by standard 4mm banana plugs

Constructed from strong fiberglass circuit board material – making it very sturdy for student use

The PA0875-001 has 2 x banana sockets & 2 x connectors

The PA0875-010 has 3 x banana sockets & 3 x connectors

Parts are fitted to the holders – there is no need to solder

Components that can be supported include: transistors, diodes, resistors, MES lamp sockets, LEDs with their resistors or diodes

Fitted with plastic feet to protect benches from being scratched from sharp wires & parts

Size: 73 x 38mm

Price: $7.55 (2 way component holder); $8.65 (3 way component holder)



BATTERIES

BATTERY 9V Code: BATT9 Toshiba Heavy Duty Price: $2.50

AA BATTERY Code: BATTAA AA Toshiba Heavy Duty. Pack of 4. Price: $2.51

AA ALKALINE BATTERY Code: BATTALK AA Alkaline Battery. Pack of 4. Price: $3.88

AA ALKALINE BATTERY Code: BATTALK40 AA Alkaline Battery. Pack of 40. Price: $19.67

AAA ALKALINE Code: BATTAAA AAA Alkaline Battery. Pack of 4. Price: $3.88

AAA ALKALINE Code: BATTAAA40 AAA Alkaline Battery. Pack of 40. Price: $19.67

D-CELL BATTERY Code: BATTD Toshiba Heavy Duty. Price: $2.85

N-SIZE BATTERY Code: BATTN Super Heavy Duty. Pack of 2. Price: $3.99

BUTTONCELL 3.6V LITHIUM ION BATTERY Code: BATTL3.6 Rechargeable button cell 3.6V. Price: $4.67



EQUIPMENT & TOOLS


CLINOMETER-MK 2

Code: CLINOMK2

· A compact Clinometer with no external moving parts and a combined 'sighting' angle-reading eyepiece

· A viewing window on the side of the Clinometer allows a second person to check a reading

· All angles in degrees followed by a plus or minus to indicate an upward or downward slope

· Size: 14cm dia.; Complete with product guide

Price: $36.00

CLINO Clinometer.jpg

CLINOMETER

Code: CLINO

Sturdy plastic

Price: $32.95


METER RULERS

Code: MRPH0062 (Wooden)

One metre, graduated on both edges in centimetres & millimetres. One edge reads 0 – 100 left to right, the other in reverse.

Price: $9.00

Code: MREX100 (Plastic)

One metre, graduated on one side in 0.5cm & numbered in centimetres. Reverse side graduated in millimetres & from 0 -100 in centimetres.

Price: $12.00

PROBE1820 Temperature Probe DS18B20.jpg

TEMPERATURE PROBE DS18B20

Code: PROBE1820

Water Proof DS18B20 temperature sensor.

Arduino compatible. Stainless steel tube: 35mm (length) x 6mm (diameter). Cable: 90cm (length) x 4mm (diameter).

Provides 9 to 12-bit (configurable) temperature readings which indicate the temperature of the device.

Unique 1-Wire interface requires only one port pin for communication.

Each DS18B20 contains a unique silicon serial number enabling multiple DS18B20s to exist on the same 1-Wire bus and therefore placing sensors in many different places.

Can be powered from data line. Power supply range is 3.0V to 5.5V. Measures temperatures -55°C to +125°C (±0.5°C accuracy from -10°C to +85°C).

Converts 12-bit temperature to digital word in 750 ms (max.).

Price: $5.50

PA-171 Digital Thermometer.jpg

DIGITAL MULTI-PURPOSE THERMOMETER

Code: PA-171

Pocket stem digital thermometer with 145mm stainless steel probe; automatic shut off. Range: - 50°C to 300° C in 1 degrees C.

Hold function. Max./ Min. key to view maximum and minimum.

Overall length 235mm

Supplied with plastic storage tube. Battery included.

Price: $26.95

VERNCAL Vernier Calipers IME Type.jpg

VERNIER CALLIPERS- IME TYPE –

0 -15CM WITH CASE

Code: VERNCAL

IME type, plated steel with dual scale 0-15cm x 0.1mm & 6x1/128”.

Thumb movement.

In case.

Price: $24.95


HANDHELD DIGITAL TACHOMETER

Code: TACHOHH

Non-contact digital laser photo tachometer.

Large 18mm, 5 digit LCD display.

Testing Range: 2.5 ~ 99,999 RPM (rate / min).

Has a wide range of applications including measuring rotating speed of machine, motors, model cars, wheels, lathe for metal or wood cutting work etc.

Resolution: 0.1 RPM (2.5 ~ 999.9 RPM) / 1 RPM (over 1,000 RPM)

Requires 9V battery (not included)

Price: $61.95

LB4064-101 Timer Multi Function 220 240v AC.jpg

TIMER-MULTI FUNCTION 220/240v AC

Code: LB4064-101

· Versatile timer with a bright red digital display for classroom work

· LED 6 digits; Auto-ranging permits times up to 999.999S x 0.0001S and up to 999.999S by 0.001S

· 240V

· AC lamp or LED power is provided on rear panel for PhotoGates.. Ideal for use with the IEC Photogate Kit (MF0138-001), suitable for Linear Air Track - NOTE: This can be ordered through Scorpio Technology if required.

· A special constant current output is provided on the rear panel for the IEC 'Free Fall' experiment (MF1871-401) to energise the solenoid that holds the steel balls. The instant the timing begins, automatically the ball is made to drop. This makes the 'Free Fall' experiment very easy and accurate.

· Timer is microprocessor controlled and is very fast

· Selectable modes are: Start/Stop, PhotoGate, Period and Pendulum. Stores 20 memories that can be added, averaged, purged or cleared.

· See the PDF file on the IEC website for full details.

Price: $343.00

NOTE: Price: $209.00 (IEC Photogate Kit MF0138-001); $297.00 IEC “Free Fall”, Solenoid Release Experiment (MF1871-401)



POWER SUPPLIES

LB4090-001 Transformer 240V 12V.jpg

TRANSFORMER 240V/12V

Code: LB4090-001

Genuine IEC transformer

240V / 12V AC; Supplies 12V AC to 3 separate circuits up to a load of 12 Amps

Can run 3x 'Hodson' Light Boxes or similar

The mains cable is not removable

Outputs are via 3 pairs of 4mm socket head spin free IEC terminals.

Price: $195.00

POWSOCMT Power Socket Mount.jpg

POWER SOCKET MOUNT

Code: POWSOCMT

1 x 2.1mm Female Plastic Chassis Mount DC Power Socket

Price: $1.55


POWER PACK 12V

Code: POWPK2

AC 100-240V-Converter-Adapter

DC-12V-500mA-1.0A.

5.5mm-x-2.1mm

Price: $19.52
